TOGIALED

TJ-S1005CL4T5ALC7K-A5

Green 573nm LED Indication - Discrete 1.8V~2.4V 0402

0402ROHS CompliantActive

LED GREEN WATER CLEAR 0402 SMD

Manufacturer: TOGIALED
Manufacturer part #: TJ-S1005CL4T5ALC7K-A5
Store part #: C917187
Package / case: 0402
Category: LED Indication - Discrete
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

4,800 in stock

#C917187

Stock & price checked 10 days ago

Quantity	Unit price	Pack price
20+	₹4.48	₹89.60
200+	₹3.55	₹710.00
600+	₹3.03	₹1,818.00
5,000+	₹2.55	₹12,750.00
10,000+	₹2.29	₹22,900.00
20,000+	₹2.13	₹42,600.00

Quantity (min 20, multiples of 20)

20 × ₹4.48

₹89.60

excl. GST

₹105.73 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 15-18 working days
GST invoice with every order
Standard pack: 5,000 per reel

TJ-S1005CL4T5ALC7K-A5

₹89.60 for 20 + GST

Need this with the rest of your board? Upload the BOM — we price every line.Upload BOM

Specifications

Peak Wavelength: 573nm
Lens Color: Water Clear
Luminous Intensity: 80mcd
Viewing Angle: 120°
Forward Current: 20mA
Illumination Color: Yellow Green
Lamp Holder Type: 1mm x 0.5mm square LED
Voltage - Forward(Vf): 1.8V~2.4V
Operating Temperature: -40℃~+80℃
Wavelength: 565nm~575nm
Diode Configuration: Discrete Diode

Packaging & compliance

RoHS: ROHS Compliant
Lifecycle: Active
ECCN: EAR99
Packaging: Tape & Reel (TR)
Standard pack: 5,000 / Reel
Sold per: Piece
Minimum order: 20 (multiples of 20)
Unit weight: 0.024 g

Overview

Applications

Backlight
Indicator light

Key features

1.0mm × 0.5mm SMT LED, 0.4mm height
Low power consumption
Wide viewing angle
Packaging: 5000 pcs/reel
RoHS compliant
