TLC2201AIDR

50mA 1 200uV 2.7V/us 115dB 1pA 1.1mA 1.9MHz Rail-to-rail output SOIC-8 Instrumentation, Op Amps, Buffer Amps RoHS

SOIC-8ROHS3 CompliantActive

Manufacturer: TI
Manufacturer part #: TLC2201AIDR
Store part #: C2060423
Package / case: SOIC-8
Category: Instrumentation, Op Amps, Buffer Amps
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

2,658 in stock

#C2060423

Stock & price checked 12 days ago

Quantity	Unit price	Pack price
1+	₹678.42	₹678.42
10+	₹609.69	₹6,096.90
30+	₹565.89	₹16,976.70
100+	₹523.62	₹52,362.00

Quantity (min 1)

1 × ₹678.42

₹678.42

excl. GST

₹800.54 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 15-18 working days
GST invoice with every order
Standard pack: 2,500 per reel

TLC2201AIDR

₹678.42 for 1 + GST

Need this with the rest of your board? Upload the BOM — we price every line.Upload BOM

Specifications

Output Current: 50mA
Number of Channels: 1
Vos - Input Offset Voltage: 200uV
Slew Rate: 2.7V/us
Input Offset Current(Ios): 0.5pA
Operating Temperature: -40℃~+85℃
Common Mode Rejection Ratio(CMRR): 115dB
Ib - Input Bias Current: 1pA
Input Offset Voltage Drift(Vos TC): 500nV/℃
Quiescent Current: 1.1mA
Gain Bandwidth Product: 1.9MHz
Features: ESD protection;Latch-up suppression
Input Voltage Noise Density: 8nV/√Hz@1kHz
Dual Supply: -8V~-2.3V;2.3V~8V
Rail to Rail: Rail-to-rail output

Packaging & compliance

RoHS: ROHS3 Compliant
Lifecycle: Active
ECCN: EAR99
Packaging: Tape & Reel (TR)
Standard pack: 2,500 / Reel
Sold per: Piece
Minimum order: 1
Unit weight: 0.598 g

Overview

Applications

High-impedance, low-level signal conditioning applications
Single-supply or dual-supply configuration applications
