TM1729
2.5V~5.5V 52 segments 2-Wire Serial Interface 7.5uA LQFP-64(7x7) Display Drivers
LQFP-64(7x7)RoHSActive
52SEG X 4COM LCD Driver Chip
- Manufacturer
- TM(Shenzhen Titan Micro Elec)
- Manufacturer part #
- TM1729
- Store part #
- C125160
- Package / case
- LQFP-64(7x7)
- Category
- Display Drivers
- Packaging
- Tray
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,073 in stock
#C125160
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹105.76 | ₹105.76 |
| 10+ | ₹87.91 | ₹879.10 |
| 30+ | ₹79.00 | ₹2,370.00 |
| 250+ | ₹61.80 | ₹15,450.00 |
| 500+ | ₹56.36 | ₹28,180.00 |
| 1,000+ | ₹53.75 | ₹53,750.00 |
1 × ₹105.76
₹105.76
excl. GST
₹124.80 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 250 per tray
TM1729
₹105.76 for 1 + GST
Specifications
- Voltage - Supply
- 2.5V~5.5V
- Frequency
- 56kHz
- Operating Temperature
- -40℃~+85℃
- Display Configurations(bit)
- 52x4 bit
- Pd - Power Dissipation
- 640mW
- Display Configurations(Segment)
- 52 segments
- Interface
- 2-Wire Serial Interface
- Features
- Built-in oscillator
- Quiescent Current (Iq)
- 5uA
- Current - Supply
- 7.5uA
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Moisture sensitivity
- MSL 3 (168 hours)
- Packaging
- Tray
- Standard pack
- 250 / Tray
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 7.92 g
Overview
TM1729 is a low-power LCD display driver controller IC designed for field-type applications. It features 52 SEG outputs and 4 COM outputs, with built-in 52×4 = 208-bit DDRAM. Data is transmitted via 2-wire serial interface (SCL, SDA). It supports 1/3 Bias and 1/2 Bias drive modes, as well as Line and Frame inversion modes. It is widely applicable in energy meters, power meters, and other instrumentation.
Applications
- Energy meter
- Power meter
Key features
- Operating voltage range: 2.5~5.5V
- LCD drive output: 52 SEG×4 COM
- Built-in DDRAM capacity: 52×4 = 208 bit
- LCD drive mode: 1/3 Bias, 1/2 Bias
- LCD inversion mode: Line, Frame
- Serial data input interface: SCL, SDA
- Low power consumption design
- Built-in oscillator circuit with standby mode
- Built-in power-on reset with blink mode
- Package: TSSOP48, SSOP48, LQFP64
