JSCJDatasheet (PDF)
US2JF
50ns 1 Independent 600V 1.3V@2A 2A DO-214AD Single Diodes RoHS
DO-214ADROHS CompliantActive
Diode 600V 2A DO-214AD
- Manufacturer
- JSCJ
- Manufacturer part #
- US2JF
- Store part #
- C2923929
- Package / case
- DO-214AD
- Category
- Single Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,000 in stock
#C2923929
Stock & price checked 8 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 20+ | ₹4.58 | ₹91.60 |
| 200+ | ₹3.63 | ₹726.00 |
| 600+ | ₹3.08 | ₹1,848.00 |
| 3,000+ | ₹2.77 | ₹8,310.00 |
| 9,000+ | ₹2.49 | ₹22,410.00 |
| 21,000+ | ₹2.34 | ₹49,140.00 |
20 × ₹4.58
₹91.60
excl. GST
₹108.09 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
US2JF
₹91.60 for 20 + GST
Specifications
- Reverse Recovery Time (trr)
- 50ns
- Diode Configuration
- 1 Independent
- Operating Junction Temperature Range
- -55℃~+150℃
- Voltage - DC Reverse (Vr) (Max)
- 600V
- Voltage - Forward(Vf@If)
- 1.3V@2A
- Reverse Leakage Current (Ir)
- 5uA@600V
- Non-Repetitive Peak Forward Surge Current
- 50A
- Current - Rectified
- 2A
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 20 (multiples of 20)
- Unit weight
- 0.062 g
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | ES2JF#C2923933JSCJ · DO-214AD | JSCJ | DO-214AD | 180 | ₹4.10 · 180 in stock | View |
 | RS2JF#C2923917JSCJ · DO-214AD | JSCJ | DO-214AD | 2,620 | ₹3.78 · 2,620 in stock | View |
 | RS2KF#C3019339JSCJ · DO-214AD | JSCJ | DO-214AD | 2,440 | ₹3.82 · 2,440 in stock | View |
 | RS3MF#C5293872JSCJ · SMAF(DO-214AD) | JSCJ | SMAF(DO-214AD) | 1,780 | ₹5.31 · 1,780 in stock | View |
 | US2KF#C3019373JSCJ · DO-214AD | JSCJ | DO-214AD | On request | ₹4.88 · 0 in stock | View |
