VISHAYDatasheet (PDF)
VS-HFA04TB60-M3
28ns 1 Independent 600V 1.5V@4A 4A TO-220AC-2 Single Diodes RoHS
TO-220AC-2ROHS3 CompliantActive
Diode 600V 4A TO-220AC-2
- Manufacturer
- VISHAY
- Manufacturer part #
- VS-HFA04TB60-M3
- Store part #
- C506532
- Package / case
- TO-220AC-2
- Category
- Single Diodes
- Packaging
- Tube-packed
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
13 in stock
#C506532
Stock & price checked 7 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹121.35 | ₹121.35 |
| 10+ | ₹96.79 | ₹967.90 |
| 50+ | ₹83.49 | ₹4,174.50 |
| 100+ | ₹68.15 | ₹6,815.00 |
| 500+ | ₹61.39 | ₹30,695.00 |
| 1,000+ | ₹58.32 | ₹58,320.00 |
1 × ₹121.35
₹121.35
excl. GST
₹143.19 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 50 per tube
VS-HFA04TB60-M3
₹121.35 for 1 + GST
Specifications
- Reverse Recovery Time (trr)
- 28ns
- Operating Junction Temperature Range
- -55℃~+150℃
- Diode Configuration
- 1 Independent
- Voltage - DC Reverse (Vr) (Max)
- 600V
- Pd - Power Dissipation
- 25W
- Voltage - Forward(Vf@If)
- 1.5V@4A
- Reverse Leakage Current (Ir)
- 170nA@600V
- Non-Repetitive Peak Forward Surge Current
- 25A
- Current - Rectified
- 4A
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tube-packed
- Standard pack
- 50 / Tube
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 2.68 g
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | MUR20H60#C5355161JSCJ · TO-220-2L | JSCJ | TO-220-2L | 75 | ₹62.37 · 75 in stock | View |
 | STTH1506#C2978904Tokmas · TO-220-2 | Tokmas | TO-220-2 | 15 | ₹43.04 · 15 in stock | View |
 | ESTF30SS60SC#C5353727MASPOWER · TO-220AC | MASPOWER | TO-220AC | 25 | ₹140.16 · 25 in stock | View |
 | MUR860#C961869YANGJIE · TO-220-2 | YANGJIE | TO-220-2 | 115 | ₹64.34 · 115 in stock | View |
 | SPT8U120SA2#C49863282SPTECH · TO-220-2 | SPTECH | TO-220-2 | 50 | ₹67.50 · 50 in stock | View |
