XTR105UA/2K5
SOIC-14 Sensor and Detector Interfaces RoHS
4-20mA Current Transmitter with Sensor Excitation and Linearization
- Manufacturer
- TI
- Manufacturer part #
- XTR105UA/2K5
- Store part #
- C38854
- Package / case
- SOIC-14
- Category
- Sensor and Detector Interfaces
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
5,898 in stock
#C38854
Stock & price checked 3 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹425.19 | ₹425.19 |
| 10+ | ₹368.81 | ₹3,688.10 |
| 30+ | ₹333.69 | ₹10,010.70 |
| 100+ | ₹297.69 | ₹29,769.00 |
| 500+ | ₹281.43 | ₹1,40,715.00 |
| 1,000+ | ₹274.50 | ₹2,74,500.00 |
1 × ₹425.19
₹425.19
excl. GST
₹501.72 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 2,500 per reel
XTR105UA/2K5
₹425.19 for 1 + GST
Specifications
- Features
- Programmable gain
- Operating Temperature
- -40℃~+85℃
- Voltage - Supply
- 7.5V~36V
- Resolution (Bits)
- -;-
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 3 (168 hours)
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,500 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.264 g
Overview
The XTR105 is a monolithic 4-20mA, 2-wire current transmitter with two precision current sources. It provides complete current excitation for platinum RTD temperature sensors and bridges, instrumentation amplifiers, and current output circuitry on a single integrated circuit. Versatile linearization circuitry provides a 2nd-order correction to the RTD, typically achieving a 40:1 improvement in linearity. Instrumentation amplifier gain can be configured for a wide range of temperature or pressure measurements. Total unadjusted error of the complete current transmitter is low enough to permit use without adjustment in many applications. This includes zero output current drift, span drift, and nonlinearity. The XTR105 operates on loop power-supply voltages down to 7.5V. The XTR105 is available in DIP-14 and SO-14 surfacemount packages and is specified for the -40°C to +85°C industrial temperature range.
Applications
- INDUSTRIAL PROCESS CONTROL
- FACTORY AUTOMATION
- SCADA REMOTE DATA ACQUISITION
- REMOTE TEMPERATURE AND PRESSURE TRANSDUCERS
- Pt100 NONLINEARITY CORRECTION
Key features
- LOW UNADJUSTED ERROR
- TWO PRECISION CURRENT SOURCES: 800µA each
- LINEARIZATION
- 2- OR 3-WIRE RTD OPERATION
- LOW OFFSET DRIFT: 0.4µV/°C
- LOW OUTPUT CURRENT NOISE: 30nA_PP
- HIGH PSR: 110dB minimum
- HIGH CMR: 86dB minimum
- WIDE SUPPLY RANGE: 7.5V to 36V
- DIP-14 AND SO-14 PACKAGES
