DIODES

ZXTN19020DGTA

Bipolar (BJT) Transistor NPN 20V 9A 160MHz 12.8W Surface Mount SOT-223

SOT-223ROHS CompliantActive

TRANS NPN 20V 9A SOT-223

Manufacturer: DIODES
Manufacturer part #: ZXTN19020DGTA
Store part #: C151613
Package / case: SOT-223
Category: Single Bipolar Transistors
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

51 in stock

#C151613

Stock & price checked 5 days ago

Quantity	Unit price	Pack price
1+	₹116.07	₹116.07
10+	₹94.61	₹946.10
30+	₹83.77	₹2,513.10
100+	₹73.15	₹7,315.00
500+	₹66.69	₹33,345.00
1,000+	₹63.56	₹63,560.00

Quantity (min 1)

1 × ₹116.07

₹116.07

excl. GST

₹136.96 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 15-18 working days
GST invoice with every order
Standard pack: 3,000 per reel

ZXTN19020DGTA

₹116.07 for 1 + GST

Need this with the rest of your board? Upload the BOM — we price every line.Upload BOM

Specifications

Operating Temperature: -55℃~+150℃
Current - Collector Cutoff: 500nA
Transition frequency(fT): 160MHz
Collector - Emitter Voltage VCEO: 20V
Emitter-Base Voltage VEBO: 7V
DC Current Gain: 130
Current - Collector(Ic): 9A
Pd - Power Dissipation: 12.8W
Number: 1 NPN
type: NPN
Vce Saturation(VCE(sat)): 35mV

Packaging & compliance

RoHS: ROHS Compliant
Lifecycle: Active
ECCN: EAR99
Packaging: Tape & Reel (TR)
Standard pack: 3,000 / Reel
Sold per: Piece
Minimum order: 1
Unit weight: 0.216 g

Overview

Applications

PSU Start-Up Circuit
DC-DC Converters
Motor Drive Relay, Lamp and Solenoid Drive

Key features

BVCEX > 70V
BVCEO > 20V
BVECO > 4.5V
lC = 9A High Continuous Current
Low Saturation Voltage VCE(sat) < 35mV @ 1A
RCE(sat) = 20mΩ
Complementary PNP Type: ZXTP19020DG Lead-Free Finish; RoHS Compliant
Halogen and Antimony Free. “Green” Device
Qualified to AEC-Q101 Standards for High Reliability
