STDatasheet (PDF)
1.5KE350A
618VC Clamp 4A@8/20us Ipp TVS DIODE DO-201
DO-201ROHS3 CompliantActive
TVS DIODE 299VWM 618VC DO-201
- Manufacturer
- ST
- Manufacturer part #
- 1.5KE350A
- Store part #
- C132966
- Package / case
- DO-201
- Category
- TVS Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
13 in stock
#C132966
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹145.81 | ₹145.81 |
| 10+ | ₹118.21 | ₹1,182.10 |
| 30+ | ₹104.53 | ₹3,135.90 |
| 100+ | ₹90.84 | ₹9,084.00 |
| 600+ | ₹82.79 | ₹49,674.00 |
| 1,200+ | ₹78.45 | ₹94,140.00 |
1 × ₹145.81
₹145.81
excl. GST
₹172.06 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 600 per box
1.5KE350A
₹145.81 for 1 + GST
Specifications
- Clamping Voltage
- 618V
- Peak Pulse Current (Ipp)
- 4A@8/20us
- Peak Pulse Power Dissipation (Ppp)
- 1.5kW@10/1000us
- Number of Channels
- 1
- Voltage - Breakdown
- 350V
- type
- TVS
- Polarity
- Unidirectional
- Reverse Leakage Current (Ir)
- 1uA
- Reverse Stand-Off Voltage (Vrwm)
- 299V
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 600 / Box
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 1.071 g
Overview
Transil diodes provide high overvoltage protection by clamping action. Their instantaneous response to transient overvoltages makes them particularly suited to protect voltage sensitive devices such as MOS Technology and low voltage supplied IC's.
Key features
- Peak pulse power: 1500 W (10/1000 μs)
- Breakdown voltage range From 6.8 V to 440 V
- Uni and bidirectional types
- Low clamping factor
- Fast response time
- UL 497B file number: QVGQ2. E136224
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
| 1.5KE350ARL#C3705236ST · DO-201 | ST | DO-201 | 358 | ₹100.02 · 358 in stock | View | |
 | 1.5KE350A#C223919Littelfuse · DO-201 | Littelfuse | DO-201 | On request | ₹108.98 · 0 in stock | View |
| 1.5KE350A#C3721011SMC · DO-201AD | SMC | DO-201AD | On request | ₹42.02 · 0 in stock | View | |
| 1.5KE350A#C3720116Taiwan Semiconductor · DO-201 | Taiwan Semiconductor | DO-201 | On request | ₹42.36 · 0 in stock | View | |
| M1.5KE400AE3/TR#C6981303MICROCHIP · DO-201AA(DO-27) | MICROCHIP | DO-201AA(DO-27) | On request | ₹2,178.12 · 0 in stock | View | |
