1.5SMC33A
nan
- Manufacturer
- BOURNS
- Manufacturer part #
- 1.5SMC33A
- Store part #
- C19192049
- Package / case
- DO-214AB
- Category
- TVS Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
20 in stock
#C19192049
Stock & price checked 4 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹62.55 | ₹62.55 |
| 10+ | ₹61.69 | ₹616.90 |
| 30+ | ₹61.04 | ₹1,831.20 |
| 100+ | ₹60.41 | ₹6,041.00 |
1 × ₹62.55
₹62.55
excl. GST
₹73.81 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
1.5SMC33A
₹62.55 for 1 + GST
Specifications
- Clamping Voltage
- 45.7V
- Operating Temperature
- -55℃~+150℃
- Peak Pulse Power Dissipation (Ppp)
- 1.5kW
- Number of Channels
- 1
- Voltage - Breakdown
- 34.7V
- type
- TVS
- Polarity
- Unidirectional
- Reverse Leakage Current (Ir)
- 1uA
- Reverse Stand-Off Voltage (Vrwm)
- 28.2V
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.725 g
Overview
The portable communications, computing, and video equipment market challenges the semiconductor industry to develop smaller electronic components. Bourns offers transient voltage suppressor diodes for surge and ESD protection applications in the compact chip package DO-214AB (SMC) size format. This TVS diode series provides breakdown voltage options from 6.8 V to 550 V. Typical fast response time for unidirectional devices from 0 V to minimum breakdown voltage is less than 1.0 picosecond, and less than 5.0 picoseconds for bidirectional devices. Bourns chip diodes comply with JEDEC standards, are easy to handle with standard placement equipment, and their flat profile reduces rolling.
Applications
- Portable communication devices
- Computing devices
- Video devices
Key features
- RoHS compliant and halogen-free
- Surface mount SMC package
- Breakdown voltage: 6.8 to 550V
- Peak pulse power: 1500W
- Typical temperature coefficient: ΔVBR = 0.1% × VBR × 25°C × ΔT
- IEC 61000-4-2 ESD compliant (Level 4 minimum)
- IEC 61000-4-4 EFT compliant
- IEC 61000-4-5 surge compliant
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | 1.5SMC33A(MS)#C22365410MSKSEMI · SMC | MSKSEMI | SMC | 1,455 | ₹18.65 · 1,455 in stock | View |
 | 1.5SMC33A-E3/57T#C1975402VISHAY · SMC(DO-214AB) | VISHAY | SMC(DO-214AB) | 663 | ₹63.13 · 663 in stock | View |
 | SMCJ28A#C17702974MSKSEMI · SMC(DO-214AB) | MSKSEMI | SMC(DO-214AB) | 1,630 | ₹13.02 · 1,630 in stock | View |
 | SMCJ28A#C20623824Brightking · SMC(DO-214AB) | Brightking | SMC(DO-214AB) | 255 | ₹16.35 · 255 in stock | View |
 | SMCJ28A#C20883365OTW · SMC(DO-214AB) | OTW | SMC(DO-214AB) | 3,060 | ₹9.55 · 3,060 in stock | View |
