5.0SMDJ20CA
32.4VC Clamp 155A Ipp TVS DIODE DO-214AB(SMC)
- Manufacturer
- BOURNS
- Manufacturer part #
- 5.0SMDJ20CA
- Store part #
- C3719801
- Package / case
- DO-214AB(SMC)
- Category
- TVS Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
25 in stock
#C3719801
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹479.75 | ₹479.75 |
| 10+ | ₹472.65 | ₹4,726.50 |
| 30+ | ₹468.14 | ₹14,044.20 |
| 100+ | ₹463.41 | ₹46,341.00 |
1 × ₹479.75
₹479.75
excl. GST
₹566.11 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
5.0SMDJ20CA
₹479.75 for 1 + GST
Specifications
- Clamping Voltage
- 32.4V
- Operating Temperature
- -55℃~+150℃
- Peak Pulse Current (Ipp)
- 155A
- Peak Pulse Power Dissipation (Ppp)
- 5kW
- Number of Channels
- 1
- Voltage - Breakdown
- 22.2V
- type
- TVS
- Polarity
- Bidirectional
- Reverse Leakage Current (Ir)
- 2uA
- Reverse Stand-Off Voltage (Vrwm)
- 20V
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.552 g
Overview
Portable communications, computing and video equipment manufacturers are challenging the semiconductor industry to develop increasingly higher power density circuit protection components. The Transient Voltage Suppressor series offers a choice of Working Peak Reverse Voltage from 5 V up to 170 V and Breakdown Voltage up to 209 V. Typical fast response times are less than 1.0 ps from 0 V to Breakdown Voltage. Chip Diodes conform to JEDEC standards, are easy to handle with standard pick and place equipment and the flat configuration minimizes roll away.
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | 5.0SMDJ20CA#C384923Leiditech · DO-214AB(SMC) | Leiditech | DO-214AB(SMC) | 4 | ₹133.13 · 4 in stock | View |
 | 5.0SMDJ20CA#C2990398Liown · SMC(DO-214AB) | Liown | SMC(DO-214AB) | 2,485 | ₹34.69 · 2,485 in stock | View |
 | 5.0SMDJ20CA/TR13#C522678Brightking · SMC(DO-214AB) | Brightking | SMC(DO-214AB) | 31 | ₹57.34 · 31 in stock | View |
 | 5.0SMDJ20CA#C5270686YFW · DO-214AB(SMC) | YFW | DO-214AB(SMC) | 400 | ₹75.24 · 400 in stock | View |
 | 5.0SMDJ20CA#C406695DOWO · SMC(DO-214AB) | DOWO | SMC(DO-214AB) | 10,605 | ₹44.96 · 10,605 in stock | View |
