ADUC7029BBCZ62
ARM Cortex-M3 32 Bit 44MHz BGA-49 Microcontrollers RoHS
BGA-49ROHS3 CompliantActive
Precision analog microcontroller, 12-bit analog I/O, ARM7TDMI MCU
- Manufacturer
- ADI
- Manufacturer part #
- ADUC7029BBCZ62
- Store part #
- C660100
- Package / case
- BGA-49
- Category
- Microcontrollers
- Packaging
- Tray
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
10 in stock
#C660100
Stock & price checked 9 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹1,987.44 | ₹1,987.44 |
| 10+ | ₹1,894.09 | ₹18,940.90 |
| 30+ | ₹1,732.27 | ₹51,968.10 |
| 100+ | ₹1,591.07 | ₹1,59,107.00 |
1 × ₹1,987.44
₹1,987.44
excl. GST
₹2,345.18 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 640 per tray
ADUC7029BBCZ62
₹1,987.44 for 1 + GST
Specifications
- DAC (Bit)
- 12bit
- ADC (Bit)
- 12bit
- Number of I/O
- 22
- Operating Temperature
- -40℃~+125℃
- Voltage - Supply
- 2.7V~3.6V
- Program Memory Type
- FLASH
- Program Storage Size
- 31KB
- CPU Core
- ARM Cortex-M3
- Core Size
- 32 Bit
- CPU Maximum Speed
- 44MHz
- Oscillator Type
- Built-in+External
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- 3A991A2
- Packaging
- Tray
- Standard pack
- 640 / Tray
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.024 g
Overview
Applications
- Industrial control and automation systems
- Smart sensors, precision instrumentation
- Base station systems, optical networking
Key features
- Analog I/O Multichannel, 12-bit, 1 MSPS ADC
- Up to 16 ADC channels
- Fully differential and single-ended modes
- 0V to V_REF analog input range
- 12-bit voltage output DACs
- Up to 4 DAC outputs available
- On-chip voltage reference
- On-chip temperature sensor (±3°C)
- Voltage comparator
- ARM7TDMI core, 16-bit/32-bit RISC architecture
- JTAG port supports code download and debug
- Trimmed on-chip oscillator (±3%)
- External watch crystal
- External clock source up to 44 MHz
- 41.78 MHz PLL with programmable divider
- 62 kB Flash/EE memory, 8 kB SRAM
- in-circuit download, JTAG-based debug
- Software-triggered in-circuit reprogrammability
- UART, 2xI²C and SPI serial I/O
- Up to 40-pin GPIO port
- 4x general-purpose timers
- Wake-up and watchdog timers (WDT)
- Power supply monitor
- 3-phase, 16-bit PWM generator
- Programmable logic array (PLA)
- External memory interface, up to 512 kB
- Specified for 3 V operation
- Active mode: 11 mA at 5 MHz, 40 mA at 41.78 MHz
- From 40-lead 6 mmx6 mm LFCSP to 80-lead LQFP
- Fully specified for -40°C to +125°C operation
- Low cost QuickStart development system
- Full third-party support
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
| ADUC7029BBCZ62-RL#C660103ADI · BGA-49 | ADI | BGA-49 | On request | ₹1,385.10 · 0 in stock | View | |
