TECH PUBLICDatasheet (PDF)
AZC002-02N
15VC Clamp 6A@8/20us Ipp ESD DIODE SOT-143
SOT-143RoHSActive
ESD DIODE 5VWM 15VC SOT-143
- Manufacturer
- TECH PUBLIC
- Manufacturer part #
- AZC002-02N
- Store part #
- C2987060
- Package / case
- SOT-143
- Category
- TVS Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
3,610 in stock
#C2987060
Stock & price checked 11 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹18.52 | ₹92.60 |
| 50+ | ₹14.87 | ₹743.50 |
| 150+ | ₹13.04 | ₹1,956.00 |
| 500+ | ₹11.68 | ₹5,840.00 |
| 3,000+ | ₹10.29 | ₹30,870.00 |
| 6,000+ | ₹9.74 | ₹58,440.00 |
5 × ₹18.52
₹92.60
excl. GST
₹109.27 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
AZC002-02N
₹92.60 for 5 + GST
Specifications
- Clamping Voltage
- 15V
- Peak Pulse Current (Ipp)
- 6A@8/20us
- Peak Pulse Power Dissipation (Ppp)
- 100W@8/20us
- Voltage - Breakdown
- 6.5V
- type
- ESD
- Reverse Leakage Current (Ir)
- 80nA
- Reverse Stand-Off Voltage (Vrwm)
- 5V
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.03 g
Overview
Applications
- USB 2.0 power and data line
- Set-top box and digital TV
- Digital video interface (DVI)
- Notebook Computers
- SIM Ports
- 10/100 Ethernet
Key features
- Ultra low leakage: nA level
- Operating voltage: 5V
- Low clamping voltage
- Complies with following standards:
- IEC 61000-4-2 (ESD) immunity test Air discharge: ±30 kV Contact discharge: ±30 kV
- IEC61000-4-5 (Lightning) 6A (8/20μs)
- IEC61000-4-4 (EFT) 40A (5/50ns)
- RoHS Compliant
