NexperiaDatasheet (PDF)
BUK7J1R4-40HX
N-Channel 40V 190A 395W Surface Mount LFPAK56E-4
LFPAK56E-4ROHS3 CompliantActive
MOSFET N-CH 40V 190A LFPAK56E-4
- Manufacturer
- Nexperia
- Manufacturer part #
- BUK7J1R4-40HX
- Store part #
- C458262
- Package / case
- LFPAK56E-4
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,184 in stock
#C458262
Stock & price checked 9 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹221.32 | ₹221.32 |
| 10+ | ₹178.54 | ₹1,785.40 |
| 30+ | ₹155.29 | ₹4,658.70 |
| 100+ | ₹128.79 | ₹12,879.00 |
| 500+ | ₹116.86 | ₹58,430.00 |
| 1,500+ | ₹111.65 | ₹1,67,475.00 |
1 × ₹221.32
₹221.32
excl. GST
₹261.16 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 1,500 per reel
BUK7J1R4-40HX
₹221.32 for 1 + GST
Specifications
- Operating Temperature
- -55℃~+175℃
- Drain to Source Voltage
- 40V
- Current - Continuous Drain(Id)
- 190A
- Ciss-Input Capacitance
- 7.61nF
- Pd - Power Dissipation
- 395W
- Reverse Transfer Capacitance (Crss)
- 524pF
- RDS(on)
- 1.4mΩ@10V
- Number
- 1 N-channel
- Gate Charge(Qg)
- 103nC@10V
- Gate Threshold Voltage (Vgs(th))
- 3.6V
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 1,500 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.134 g
Overview
Automotive qualified N-channel MOSFET using the latest Trench 9 low ohmic superjunction technology, housed in an enhanced LFPAK56E package. This product has been fully designed and qualified to meet AEC-Q101 requirements delivering high performance and endurance.
Applications
- 12 V automotive systems
- Motors, lamps and solenoid control
- Start-Stop micro-hybrid applications
- Transmission control
- Ultra high performance power switching
Key features
- Fully automotive qualified to AEC-Q101: 175 °C rating suitable for thermally demanding environments
- Trench 9 Superjunction technology:
- Reduced cell pitch enables enhanced power density and efficiency with lower RDSon in same footprint
- Improved SOA and avalanche capability compared to standard TrenchMOS
- Tight VGS(th) limits enable easy paralleling of MOSFETs
- LFPAK Gull Wing leads:
- High Board Level Reliability absorbing mechanical stress during thermal cycling, unlike traditional QFN packages
- Visual (AOI) soldering inspection, no need for expensive x-ray equipment
- Easy solder wetting for good mechanical solder joint
- LFPAK copper clip technology:
- Improved reliability, with reduced Rth and RDSon
- Increases maximum current capability and improved current spreading
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
| PSMN1R0-40ULDX#C553218Nexperia · LFPAK56E-4 | Nexperia | LFPAK56E-4 | On request | ₹242.28 · 0 in stock | View | |
| PSMN1R0-40YSHX#C553219Nexperia · LFPAK56E-4 | Nexperia | LFPAK56E-4 | On request | ₹580.61 · 0 in stock | View | |
 | PSMNR90-40YLHX#C553356Nexperia · LFPAK56E-4 | Nexperia | LFPAK56E-4 | On request | ₹1,084.16 · 0 in stock | View |
 | BUK7J1R0-40HX#C503359Nexperia · LFPAK56E-4 | Nexperia | LFPAK56E-4 | 1 | ₹156.11 · 1 in stock | View |
| BUK9J0R9-40HX#C549993Nexperia · LFPAK56E-4 | Nexperia | LFPAK56E-4 | On request | ₹398.69 · 0 in stock | View | |
