Nexperia

BUK7M21-40EX

44W 40V 33A 21mΩ@10V 1 N-channel N-Channel LFPAK-33-8 Single FETs, MOSFETs RoHS

LFPAK-33-8ROHS3 CompliantActive

Manufacturer: Nexperia
Manufacturer part #: BUK7M21-40EX
Store part #: C503651
Package / case: LFPAK-33-8
Category: Single FETs, MOSFETs
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

1,499 in stock

#C503651

Stock & price checked 9 days ago

Quantity	Unit price	Pack price
1+	₹73.07	₹73.07
10+	₹71.55	₹715.50
30+	₹70.46	₹2,113.80
100+	₹69.36	₹6,936.00

Quantity (min 1)

1 × ₹73.07

₹73.07

excl. GST

₹86.22 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 15-18 working days
GST invoice with every order
Standard pack: 1,500 per reel

BUK7M21-40EX

₹73.07 for 1 + GST

Need this with the rest of your board? Upload the BOM — we price every line.Upload BOM

Specifications

Output Capacitance(Coss): 99pF
Ciss-Input Capacitance: 593pF
Pd - Power Dissipation: 44W
Operating Temperature: -55℃~+175℃
Drain to Source Voltage: 40V
Current - Continuous Drain(Id): 33A
Reverse Transfer Capacitance (Crss): 95pF
RDS(on): 21mΩ@10V
Number: 1 N-channel
Gate Charge(Qg): 10.7nC@10V
Vgs: ±20V
Gate Threshold Voltage (Vgs(th)): 3V
Type: N-Channel

Packaging & compliance

RoHS: ROHS3 Compliant
Lifecycle: Active
ECCN: EAR99
Packaging: Tape & Reel (TR)
Standard pack: 1,500 / Reel
Sold per: Piece
Minimum order: 1
Unit weight: 0.06 g

Overview

Standard level N-channel MOSFET using TrenchMOS technology in an LFPAK33 (Power33) package. This product has been designed and qualified to AEC Q101 standards for high-performance automotive applications.

Applications

12 V automotive systems
Motor, lamp, and solenoid control
Transmission control
Ultra-high-performance power switching

Key features

Q101 compliant
Repetitive avalanche rated
175°C temperature rating for high thermal demand environments
True standard-level gate with VGS(th) rated above 1 V at 175°C

Alternatives

Similar parts — check the datasheet before substituting.

Part		Manufacturer	Package	Stock	Price from (excl. GST)	Action
	BUK9M14-40EX#C503425Nexperia · LFPAK-33-8	Nexperia	LFPAK-33-8	3	₹95.18 · 3 in stock	View
	BUK7M3R3-40HX#C503635Nexperia · LFPAK-33-8	Nexperia	LFPAK-33-8	2,999	₹139.60 · 2,999 in stock	View
