BUK7Y3R5-40E,115
N-Channel 40V 100A 167W LFPAK56(PowerSO-8)
LFPAK56(PowerSO-8)ROHS3 CompliantActive
MOSFET N-CH 40V 100A LFPAK56(PowerSO-8)
- Manufacturer
- Nexperia
- Manufacturer part #
- BUK7Y3R5-40E,115
- Store part #
- C458224
- Package / case
- LFPAK56(PowerSO-8)
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
476 in stock
#C458224
Stock & price checked 8 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹82.32 | ₹82.32 |
| 10+ | ₹80.37 | ₹803.70 |
| 30+ | ₹79.06 | ₹2,371.80 |
| 100+ | ₹77.77 | ₹7,777.00 |
1 × ₹82.32
₹82.32
excl. GST
₹97.14 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 1,500 per reel
BUK7Y3R5-40E,115
₹82.32 for 1 + GST
Specifications
- Output Capacitance(Coss)
- 514pF
- Ciss-Input Capacitance
- 3.583nF
- Pd - Power Dissipation
- 167W
- Operating Temperature
- -55℃~+175℃
- Drain to Source Voltage
- 40V
- Current - Continuous Drain(Id)
- 100A
- Reverse Transfer Capacitance (Crss)
- 313pF
- RDS(on)
- 3.5mΩ@10V
- Number
- 1 N-channel
- Gate Charge(Qg)
- 49.4nC@10V
- Vgs
- ±20V
- Gate Threshold Voltage (Vgs(th))
- 3V
- Type
- N-Channel
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 1,500 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.126 g
Overview
Standard level N-channel MOSFET in an LFPAK56 (Power SO8) package using TrenchMOS technology. This product has been designed and qualified to AEC Q101 standard for use in high performance automotive applications.
Applications
- 12 V Automotive systems
- Motors, lamps and solenoid control
- Transmission control
- Ultra high performance power switching
Key features
- Q101 Compliant
- Repetitive avalanche rated
- Suitable for thermally demanding environments due to 175 °C rating
- True standard level gate with VGS(th) rating of greater than 1V at 175 °C
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | PSMN3R5-40YSDX#C553284Nexperia · LFPAK56(PowerSO-8) | Nexperia | LFPAK56(PowerSO-8) | 1,446 | ₹53.74 · 1,446 in stock | View |
 | BUK9Y2R8-40HX#C550046Nexperia · LFPAK56(PowerSO-8) | Nexperia | LFPAK56(PowerSO-8) | 4 | ₹441.34 · 4 in stock | View |
| PSMN5R2-60YLX#C553306Nexperia · LFPAK56(PowerSO-8) | Nexperia | LFPAK56(PowerSO-8) | 74 | ₹328.94 · 74 in stock | View | |
 | PSMN3R2-40YLDX#C553274Nexperia · LFPAK56(PowerSO-8) | Nexperia | LFPAK56(PowerSO-8) | 5 | ₹130.09 · 5 in stock | View |
 | PSMN1R7-40YLDX#C553236Nexperia · LFPAK56(PowerSO-8) | Nexperia | LFPAK56(PowerSO-8) | 4 | ₹549.22 · 4 in stock | View |
