ESHINEDatasheet (PDF)
CJC4344H
3V~3.6V I2S MSOP-10 Digital to Analog Converters (DAC) RoHS
MSOP-10ROHS CompliantActive
- Manufacturer
- ESHINE
- Manufacturer part #
- CJC4344H
- Store part #
- C41417669
- Package / case
- MSOP-10
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
17,905 in stock
#C41417669
Stock & price checked 3 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹36.16 | ₹180.80 |
| 50+ | ₹28.50 | ₹1,425.00 |
| 150+ | ₹25.23 | ₹3,784.50 |
| 500+ | ₹21.14 | ₹10,570.00 |
| 2,500+ | ₹19.32 | ₹48,300.00 |
| 4,000+ | ₹18.22 | ₹72,880.00 |
5 × ₹36.16
₹180.80
excl. GST
₹213.34 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 4,000 per reel
CJC4344H
₹180.80 for 5 + GST
Specifications
- Operating Temperature
- -40℃~+85℃
- Voltage - Supply
- 3V~3.6V
- Function
- Integrated modulator
- Number of Channels
- 2
- Resolution (Bits)
- 24;192kHz
- Interface Type
- I2S
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 3 (168 hours)
- Packaging
- Tape & Reel (TR)
- Standard pack
- 4,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.13 g
Overview
CJC4344H is a high-quality stereo DAC designed for portable multimedia applications. The device is a complete stereo digital-to-analog output system integrating interpolation, multi-bit data conversion, and output analog filtering in a 10-pin package. CJC4344H supports all mainstream audio data interface formats, with different variants differing only in the supported interface formats. The device incorporates digital interpolation, third-order multi-bit Δ-Σ DAC, digital de-emphasis, and analog filtering. CJC4344H is available in a 10-pin MSOP package, with a commercial-grade operating temperature range of -40℃ ~ +85℃.
Applications
- Handheld gaming devices
- Mobile multimedia devices
- DVD players
- Digital televisions
Key features
- DAC SNR 96dB (A-weighted)
- THD+N -92dB
- Architecture: filtered line-level output, common-mode voltage at VCC/2
- Supports sample rates up to 192 kHz
- 24-bit I²S input
- Compact 10-pin MSOP package
