JSCJDatasheet (PDF)
CJSMCJ78A
124.7VC Clamp 11.9A@10/1000us Ipp TVS DIODE SMCG
SMCGROHS CompliantActive
TVS DIODE 78VWM 124.7VC SMCG
- Manufacturer
- JSCJ
- Manufacturer part #
- CJSMCJ78A
- Store part #
- C7499216
- Package / case
- SMCG
- Category
- TVS Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,445 in stock
#C7499216
Stock & price checked 9 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹22.23 | ₹111.15 |
| 50+ | ₹17.29 | ₹864.50 |
| 150+ | ₹15.17 | ₹2,275.50 |
| 500+ | ₹12.54 | ₹6,270.00 |
| 3,000+ | ₹11.36 | ₹34,080.00 |
| 6,000+ | ₹10.65 | ₹63,900.00 |
5 × ₹22.23
₹111.15
excl. GST
₹131.16 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
CJSMCJ78A
₹111.15 for 5 + GST
Specifications
- Clamping Voltage
- 124.7V
- Peak Pulse Current (Ipp)
- 11.9A@10/1000us
- Peak Pulse Power Dissipation (Ppp)
- 1.5kW@10/1000us
- Number of Channels
- 1
- Voltage - Breakdown
- 95.73V
- type
- TVS
- Polarity
- Unidirectional
- Reverse Leakage Current (Ir)
- 5uA
- Reverse Stand-Off Voltage (Vrwm)
- 78V
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.365 g
Overview
Applications
- Clamping Voltage
Key features
- PPP 1500W VRWM 10V - 100V
- Glass passivated chip
