TECH PUBLICDatasheet (PDF)
CM1293A-02SR
12VC Clamp 4A@8/20us Ipp SOT-143
SOT-143RoHSActive
3.3VWM 12VC SOT-143
- Manufacturer
- TECH PUBLIC
- Manufacturer part #
- CM1293A-02SR
- Store part #
- C19829445
- Package / case
- SOT-143
- Category
- TVS Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
3,390 in stock
#C19829445
Stock & price checked 12 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 10+ | ₹9.72 | ₹97.20 |
| 100+ | ₹7.63 | ₹763.00 |
| 300+ | ₹6.59 | ₹1,977.00 |
| 3,000+ | ₹5.81 | ₹17,430.00 |
| 6,000+ | ₹5.19 | ₹31,140.00 |
| 9,000+ | ₹4.87 | ₹43,830.00 |
10 × ₹9.72
₹97.20
excl. GST
₹114.70 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
CM1293A-02SR
₹97.20 for 10 + GST
Specifications
- Clamping Voltage
- 12V
- Peak Pulse Current (Ipp)
- 4A@8/20us
- Number of Channels
- 2
- Voltage - Breakdown
- 9V
- Reverse Leakage Current (Ir)
- 1nA
- Reverse Stand-Off Voltage (Vrwm)
- 3.3V
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 10 (multiples of 10)
- Unit weight
- 0.033 g
Overview
Applications
- USB 2.0 and USB 3.0 Ports
- USB OTG
- Digital video interface(DVI)
- Monitor and Flat Panel Displays
- PCI Express and Serial SATA Ports
- Gigabit Ethernet
- IEEE1394 firewire ports
- Consumer products (STB, DVD, DSC, DVC...)
Key features
- Ultra low capacitance: 1.0pF MAX (I/O to GND)
- Ultralow leakage: nA level
- Low operating voltage: 5.5V(Max)
- Low clamping voltage
- Complies with following standards:
- IEC 61000-4-2 (ESD) immunity test Air discharge: ±15kV Contact discharge: ±15kV
- IEC61000-4-4 (EFT) 40A (5/50ns)
- IEC61000-4-5 (Lightning): 4A(8/20us)
