CSD19534Q5A(TP)
57W 100V 50A 12.5mΩ@10V 1 N-channel N-Channel PDFN-8(5x6) Single FETs, MOSFETs
PDFN-8(5x6)RoHSActive
- Manufacturer
- TECH PUBLIC
- Manufacturer part #
- CSD19534Q5A(TP)
- Store part #
- C53100658
- Package / case
- PDFN-8(5x6)
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
3,372 in stock
#C53100658
Stock & price checked 12 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹66.51 | ₹66.51 |
| 10+ | ₹52.14 | ₹521.40 |
| 30+ | ₹46.13 | ₹1,383.90 |
| 100+ | ₹38.41 | ₹3,841.00 |
| 500+ | ₹35.19 | ₹17,595.00 |
| 1,000+ | ₹33.05 | ₹33,050.00 |
1 × ₹66.51
₹66.51
excl. GST
₹78.48 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 5,000 per reel
CSD19534Q5A(TP)
₹66.51 for 1 + GST
Specifications
- Output Capacitance(Coss)
- 400pF
- Ciss-Input Capacitance
- 2.8nF
- Pd - Power Dissipation
- 57W
- Configuration
- Standalone
- Drain to Source Voltage
- 100V
- Operating Temperature
- -55℃~+150℃
- Current - Continuous Drain(Id)
- 50A
- Reverse Transfer Capacitance (Crss)
- 36pF
- RDS(on)
- 12.5mΩ@10V
- Number
- 1 N-channel
- Gate Charge(Qg)
- 40nC
- Vgs
- ±20V
- Gate Threshold Voltage (Vgs(th))
- 3V
- Type
- N-Channel
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 5,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.13 g
Overview
Applications
- Load switch
- High-frequency switching and synchronous rectification
- Active clamp
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | BSC440N10NS3G-TP#C53100603TECH PUBLIC · PDFN-8(5x6) | TECH PUBLIC | PDFN-8(5x6) | 159 | ₹65.73 · 159 in stock | View |
 | TPCSD19534Q5AT#C53100604TECH PUBLIC · PDFN-8(5x6) | TECH PUBLIC | PDFN-8(5x6) | 200 | ₹66.14 · 200 in stock | View |
 | TPSIR606BDP-T1-RE3#C53100605TECH PUBLIC · PDFN-8(5x6) | TECH PUBLIC | PDFN-8(5x6) | 200 | ₹66.14 · 200 in stock | View |
 | TPIRFH7194TRPBF#C53100606TECH PUBLIC · PDFN-8(5x6) | TECH PUBLIC | PDFN-8(5x6) | 200 | ₹66.14 · 200 in stock | View |
 | TPSIR108DP-T1-RE3#C53100625TECH PUBLIC · PDFN-8(5x6) | TECH PUBLIC | PDFN-8(5x6) | 200 | ₹66.14 · 200 in stock | View |
