TECH PUBLICDatasheet (PDF)
D5V0L1B2WS
11VC Clamp 8.5A@8/20us Ipp SOD-323
SOD-323RoHSActive
5VWM 11VC SOD-323
- Manufacturer
- TECH PUBLIC
- Manufacturer part #
- D5V0L1B2WS
- Store part #
- C19829525
- Package / case
- SOD-323
- Category
- TVS Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
3,140 in stock
#C19829525
Stock & price checked 12 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 20+ | ₹3.06 | ₹61.20 |
| 200+ | ₹2.34 | ₹468.00 |
| 600+ | ₹1.94 | ₹1,164.00 |
| 3,000+ | ₹1.71 | ₹5,130.00 |
| 9,000+ | ₹1.51 | ₹13,590.00 |
| 21,000+ | ₹1.40 | ₹29,400.00 |
20 × ₹3.06
₹61.20
excl. GST
₹72.22 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
D5V0L1B2WS
₹61.20 for 20 + GST
Specifications
- Clamping Voltage
- 7V;11V
- Peak Pulse Current (Ipp)
- 8.5A@8/20us
- Number of Channels
- 1
- Voltage - Breakdown
- 9V
- Reverse Leakage Current (Ir)
- 500nA
- Reverse Stand-Off Voltage (Vrwm)
- 5V
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 20 (multiples of 20)
- Unit weight
- 0.029 g
Overview
Applications
- Cellular Handsets and Accessories
- Personal Digital Assistants
- Notebooks and Handhelds
- Portable Instrumentation
- Peripherals
- Pagers Peripherals
- Desktop and Servers
Key features
- Protects one data or power line
- Ultra low leakage: nA level
- Operating voltage: 5V
- Ultra low clamping voltage
- Complies with following standards:
- IEC 61000-4-2 (ESD) immunity test Air discharge: ±30 kV Contact discharge: ±30 kV
- IEC61000-4-4 (EFT) 40A (5/50ns)
- RoHS Compliant
