DCP3601NMR
Step-down type 800kHz~1.2MHz Adjustable 1A SOT-23-6L Voltage Regulators - DC DC Switching Regulators RoHS
SOT-23-6LROHS CompliantActive
- Manufacturer
- ST
- Manufacturer part #
- DCP3601NMR
- Store part #
- C31882414
- Package / case
- SOT-23-6L
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
214 in stock
#C31882414
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹204.19 | ₹204.19 |
| 10+ | ₹170.24 | ₹1,702.40 |
| 30+ | ₹151.73 | ₹4,551.90 |
| 100+ | ₹130.62 | ₹13,062.00 |
| 500+ | ₹121.25 | ₹60,625.00 |
| 1,000+ | ₹117.13 | ₹1,17,130.00 |
1 × ₹204.19
₹204.19
excl. GST
₹240.94 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
DCP3601NMR
₹204.19 for 1 + GST
Specifications
- Operating Temperature
- -40℃~+150℃
- Function
- Step-down type
- Frequency - Switching
- 800kHz~1.2MHz
- Number of Outputs
- 1
- Features
- Cycle-by-cycle current limiting;Overcurrent Protection;Light load efficient mode;EMI optimization (spread spectrum);Output discharge
- Output Type
- Adjustable
- Topology
- Buck
- Operating Voltage
- 3.3V~36V
- Switch tube (built-in/external)
- Built-in
- Output Current
- 1A
- Quiescent Current
- 1.4mA
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.891 g
Overview
The DCP3601 is a wide input voltage, easy-to-use synchronous buck converter capable of driving load currents up to 1 A. Its extended input range of 3.3 V to 36 V makes it suitable for a wide range of industrial applications. The DCP3601 operates at a fixed switching frequency of 1 MHz, allowing the use of small inductors to optimize solution size. An optional switching frequency dither function improves EMI performance. The device is based on a peak current mode architecture, integrating soft-start circuitry, overcurrent protection, overtemperature protection, and output overvoltage protection, housed in a SOT23-6L package.
Applications
- Major Home Appliances
- Smart Meters
- Industrial 24 V Bus Conversion
Key features
- 88% typical efficiency at 600 mA load (VIN = 24 V, VOUT = 5 V)
- 91% typical efficiency at 600 mA load (VIN = 12 V, VOUT = 5 V)
- 3.3 V to 36 V input operating voltage range
- Up to 1 A output current capability
- 110 μA input quiescent current
- 1 MHz fixed switching frequency
- Synchronous rectification
- Internal compensation network
- Peak current mode control
- Two variants: LCM for high efficiency at light load, LNM for noise-sensitive applications
- Output overvoltage protection
- Thermal shutdown
- Precision enable function
- Switching frequency dithering
- SOT23-6L package
