DMN2028UFDF-7
N-Channel 20V 7.9A 0.66W Surface Mount UDFN2020-6
UDFN2020-6ROHS3 CompliantActive
MOSFET N-CH 20V 7.9A UDFN2020-6
- Manufacturer
- DIODES
- Manufacturer part #
- DMN2028UFDF-7
- Store part #
- C6183664
- Package / case
- UDFN2020-6
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
105 in stock
#C6183664
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹19.33 | ₹96.65 |
| 50+ | ₹18.92 | ₹946.00 |
| 150+ | ₹18.64 | ₹2,796.00 |
| 500+ | ₹18.38 | ₹9,190.00 |
5 × ₹19.33
₹96.65
excl. GST
₹114.05 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
DMN2028UFDF-7
₹96.65 for 5 + GST
Specifications
- Output Capacitance(Coss)
- 98pF
- Ciss-Input Capacitance
- 907pF
- Pd - Power Dissipation
- 660mW
- Operating Temperature
- -55℃~+150℃
- Drain to Source Voltage
- 20V
- Current - Continuous Drain(Id)
- 7.9A
- Reverse Transfer Capacitance (Crss)
- 38pF
- RDS(on)
- 29mΩ@2.5V
- Number
- 1 N-channel
- Gate Charge(Qg)
- 9.8nC@4.5V
- Vgs
- ±8V
- Gate Threshold Voltage (Vgs(th))
- 1V
- Type
- N-Channel
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.04 g
Overview
This MOSFET is designed to minimize the on-state resistance (RDS(ON)) and yet maintain superior switching performance, making it ideal for high efficiency power management applications.
Applications
- Battery Management Application
- Power Management Functions
- DC-DC Converters
Key features
- 0.6mm Profile – Ideal for Low Profile Applications
- PCB Footprint of 4mm²
- Low Gate Threshold Voltage
- Fast Switching Speed
- ESD Protected Gate
- Totally Lead-Free & Fully RoHS Compliant
- Halogen and Antimony Free. “Green” Device
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | DMN2022UFDF-7#C145095DIODES · UDFN2020-6 | DIODES | UDFN2020-6 | 340 | ₹32.29 · 340 in stock | View |
 | SP20N11NQ#C41354846Siliup · PDFN-6L(2x2) | Siliup | PDFN-6L(2x2) | 2,640 | ₹5.76 · 2,640 in stock | View |
 | TPM1019ND6-1#C7472898TECH PUBLIC · DFN2X2-6L | TECH PUBLIC | DFN2X2-6L | 2,965 | ₹19.59 · 2,965 in stock | View |
 | YJQ10N02A#C919558YANGJIE · DFN2020-6L | YANGJIE | DFN2020-6L | 35 | ₹16.52 · 35 in stock | View |
 | FDMA410NZ#C890898onsemi · VDFN-6(2x2) | onsemi | VDFN-6(2x2) | On request | ₹169.70 · 0 in stock | View |
