DMN2050L-7
N-Channel 20V 5.9A 1.4W Surface Mount SOT-23
SOT-23ROHS3 CompliantActive
MOSFET N-CH 20V 5.9A SOT-23
- Manufacturer
- DIODES
- Manufacturer part #
- DMN2050L-7
- Store part #
- C154871
- Package / case
- SOT-23
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
210 in stock
#C154871
Stock & price checked 9 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹27.51 | ₹137.55 |
| 50+ | ₹21.88 | ₹1,094.00 |
| 150+ | ₹19.47 | ₹2,920.50 |
| 500+ | ₹16.47 | ₹8,235.00 |
| 3,000+ | ₹15.14 | ₹45,420.00 |
| 6,000+ | ₹14.34 | ₹86,040.00 |
5 × ₹27.51
₹137.55
excl. GST
₹162.31 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
DMN2050L-7
₹137.55 for 5 + GST
Specifications
- Output Capacitance(Coss)
- 144pF
- Ciss-Input Capacitance
- 532pF
- Pd - Power Dissipation
- 1.4W
- Operating Temperature
- -55℃~+150℃
- Drain to Source Voltage
- 20V
- Current - Continuous Drain(Id)
- 5.9A
- Reverse Transfer Capacitance (Crss)
- 117pF
- RDS(on)
- 100mΩ@2V
- Number
- 1 N-channel
- Gate Charge(Qg)
- 6.7nC@4.5V
- Vgs
- ±12V
- Gate Threshold Voltage (Vgs(th))
- 1.4V
- Type
- N-Channel
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.028 g
Overview
Key features
- Low On-Resistance
- 29mΩ @VGS = 4.5V
- 50mΩ @VGS = 2.5V
- 100mΩ @VGS = 2.0V
- Very Low Gate Threshold Voltage
- Low Input Capacitance
- Fast Switching Speed
- Totally Lead-Free & Fully RoHS Compliant
- Halogen and Antimony Free. “Green” Device
- Qualified to AEC-Q101 Standards for High Reliability
