DMN3051L-7
N-Channel 30V 4.5A 1.4W Surface Mount SOT-23
SOT-23ROHS3 CompliantActive
MOSFET N-CH 30V 4.5A SOT-23
- Manufacturer
- DIODES
- Manufacturer part #
- DMN3051L-7
- Store part #
- C155348
- Package / case
- SOT-23
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,435 in stock
#C155348
Stock & price checked 9 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹15.77 | ₹78.85 |
| 50+ | ₹12.86 | ₹643.00 |
| 150+ | ₹11.40 | ₹1,710.00 |
| 500+ | ₹10.31 | ₹5,155.00 |
| 3,000+ | ₹8.23 | ₹24,690.00 |
| 6,000+ | ₹7.79 | ₹46,740.00 |
5 × ₹15.77
₹78.85
excl. GST
₹93.04 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
DMN3051L-7
₹78.85 for 5 + GST
Specifications
- Operating Temperature
- -55℃~+150℃
- Drain to Source Voltage
- 30V
- Output Capacitance(Coss)
- 115pF
- Current - Continuous Drain(Id)
- 4.5A
- Ciss-Input Capacitance
- 424pF
- Pd - Power Dissipation
- 1.4W
- Reverse Transfer Capacitance (Crss)
- 81pF
- RDS(on)
- 64mΩ@4.5V
- Number
- 1 N-channel
- Gate Charge(Qg)
- 9nC@10V
- Gate Threshold Voltage (Vgs(th))
- 2.2V
- Type
- N-Channel
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.028 g
Overview
This next-generation MOSFET is designed to minimize on-resistance R<sub>DS(ON)</sub> while maintaining superior switching performance, making it ideal for high-efficiency power management applications.
Applications
- Load Switch - DC-DC Converter - Power Management Function
Key features
- Low on-resistance
- Low gate threshold voltage
- Low input capacitance
- Fast switching speed
- Low input/output leakage current
- Fully lead-free and RoHS compliant
- Halogen- and antimony-free, "Green" device
