DIODESDatasheet (PDF)
DMN6040SSS-13
60V 5.5A 2W Surface Mount SO-8
SO-8ROHS3 CompliantActive
MOSFET 60V 5.5A SO-8
- Manufacturer
- DIODES
- Manufacturer part #
- DMN6040SSS-13
- Store part #
- C156308
- Package / case
- SO-8
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
25 in stock
#C156308
Stock & price checked 8 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹48.28 | ₹241.40 |
| 50+ | ₹40.13 | ₹2,006.50 |
| 150+ | ₹36.62 | ₹5,493.00 |
| 500+ | ₹32.27 | ₹16,135.00 |
| 2,500+ | ₹30.32 | ₹75,800.00 |
| 5,000+ | ₹29.15 | ₹1,45,750.00 |
5 × ₹48.28
₹241.40
excl. GST
₹284.85 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 2,500 per reel
DMN6040SSS-13
₹241.40 for 5 + GST
Specifications
- Output Capacitance(Coss)
- 57pF
- Ciss-Input Capacitance
- 1.287nF
- Pd - Power Dissipation
- 2W
- Operating Temperature
- -55℃~+150℃
- Drain to Source Voltage
- 60V
- Current - Continuous Drain(Id)
- 5.5A
- Reverse Transfer Capacitance (Crss)
- 44pF
- RDS(on)
- 40mΩ@10V
- Number
- 1 N-channel
- Gate Charge(Qg)
- 22.4nC@10V
- Vgs
- ±20V
- Gate Threshold Voltage (Vgs(th))
- 3V
- Type
- N-Channel
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,500 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.388 g
Overview
This MOSFET has been designed to minimize the on-state resistance (RDS(on)) and yet maintain superior switching performance, making it ideal for high efficiency power management applications.
Applications
- Backlighting
- Power Management Functions
- DC-DC Converters
Key features
- Low On-Resistance
- Low Input Capacitance
- Fast Switching Speed
- Totally Lead-Free & Fully RoHS Compliant
- Halogen and Antimony Free. “Green” Device
- Qualified to AEC-Q101 standards for High Reliability
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | SP60N30P8#C41354982Siliup · SOP-8L | Siliup | SOP-8L | 1,450 | ₹6.73 · 1,450 in stock | View |
 | VBA1630#C416229VBsemi Elec · SO-8 | VBsemi Elec | SO-8 | 10 | ₹68.07 · 10 in stock | View |
 | AO4266#C5197350TECH PUBLIC · SOP-8 | TECH PUBLIC | SOP-8 | 2,850 | ₹39.76 · 2,850 in stock | View |
 | FDS3590-TP#C52205220TECH PUBLIC · SOP-8 | TECH PUBLIC | SOP-8 | 334 | ₹82.69 · 334 in stock | View |
 | FDS3682-TP#C52205221TECH PUBLIC · SOP-8 | TECH PUBLIC | SOP-8 | 500 | ₹104.21 · 500 in stock | View |
