DMP2900UT-7
P-Channel 20V 0.5A 0.25W Surface Mount SOT-523
SOT-523ROHS3 CompliantActive
MOSFET P-CH 20V 0.5A SOT-523
- Manufacturer
- DIODES
- Manufacturer part #
- DMP2900UT-7
- Store part #
- C5673591
- Package / case
- SOT-523
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
50 in stock
#C5673591
Stock & price checked 7 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹15.02 | ₹75.10 |
| 50+ | ₹14.82 | ₹741.00 |
| 150+ | ₹14.69 | ₹2,203.50 |
| 500+ | ₹14.55 | ₹7,275.00 |
5 × ₹15.02
₹75.10
excl. GST
₹88.62 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
DMP2900UT-7
₹75.10 for 5 + GST
Specifications
- Operating Temperature
- -55℃~+150℃
- Drain to Source Voltage
- 20V
- Current - Continuous Drain(Id)
- 500mA
- Ciss-Input Capacitance
- 49pF
- Pd - Power Dissipation
- 250mW
- Reverse Transfer Capacitance (Crss)
- 3.4pF
- RDS(on)
- 1.3Ω@1.8V
- Number
- 1 P-Channel
- Gate Charge(Qg)
- 700pC@4.5V
- Gate Threshold Voltage (Vgs(th))
- 500mV
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.014 g
Overview
This next-generation MOSFET is designed to minimize on-resistance R<sub>DS(ON)</sub> while maintaining superior switching performance, making it ideal for high-efficiency power management applications.
Applications
- DC-DC converter
- Load switch
- Power management functions
Key features
- Low on-resistance
- Low gate threshold voltage
- Low input capacitance
- Fast switching speed
- Low input/output leakage current
- ESD-protected gate
- Fully lead-free and RoHS compliant
- Halogen- and antimony-free, "green" device
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | SE2101E#C238677SINO-IC · SOT-523-3 | SINO-IC | SOT-523-3 | 2,820 | ₹4.67 · 2,820 in stock | View |
 | DMG1013T-7#C96676DIODES · SOT-523 | DIODES | SOT-523 | 1,22,450 | ₹6.91 · 1,22,450 in stock | View |
 | DMG1013T#C2830306TECH PUBLIC · SOT-523 | TECH PUBLIC | SOT-523 | 5,080 | ₹7.24 · 5,080 in stock | View |
 | SI1013R#C2830307TECH PUBLIC · SOT-523 | TECH PUBLIC | SOT-523 | 10,300 | ₹5.21 · 10,300 in stock | View |
 | TPM1013ER3#C2830309TECH PUBLIC · SOT-523 | TECH PUBLIC | SOT-523 | 2,790 | ₹10.58 · 2,790 in stock | View |
