DMP3068LVT-13
P-Channel 30V 2.8A 1.25W Surface Mount TSOT-26
TSOT-26ROHS3 CompliantActive
MOSFET P-CH 30V 2.8A TSOT-26
- Manufacturer
- DIODES
- Manufacturer part #
- DMP3068LVT-13
- Store part #
- C6183703
- Package / case
- TSOT-26
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
120 in stock
#C6183703
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹13.71 | ₹68.55 |
| 50+ | ₹13.42 | ₹671.00 |
| 150+ | ₹13.22 | ₹1,983.00 |
| 500+ | ₹13.03 | ₹6,515.00 |
5 × ₹13.71
₹68.55
excl. GST
₹80.89 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 10,000 per reel
DMP3068LVT-13
₹68.55 for 5 + GST
Specifications
- Operating Temperature
- -55℃~+150℃
- Drain to Source Voltage
- 30V
- Current - Continuous Drain(Id)
- 2.8A
- Ciss-Input Capacitance
- 708pF
- Pd - Power Dissipation
- 1.25W
- Reverse Transfer Capacitance (Crss)
- 47pF
- RDS(on)
- 105mΩ@4.5V
- Number
- 1 P-Channel
- Gate Charge(Qg)
- 7.3nC@4.5V
- Gate Threshold Voltage (Vgs(th))
- 1.3V
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 10,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.021 g
Overview
This next-generation MOSFET is designed to minimize on-resistance R<sub>DS(ON)</sub> while maintaining superior switching performance, making it ideal for high-efficiency power management applications.
Applications
- General-purpose interface switch - Power management function
Key features
- Low on-resistance
- Low gate threshold voltage
- Low input capacitance
- Fully lead-free and RoHS compliant
- Halogen and antimony free, "Green" device
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | DMP3068LVT-7#C3291374DIODES · TSOT-23-6 | DIODES | TSOT-23-6 | 10 | ₹20.37 · 10 in stock | View |
 | DMP6110SVT-7#C461098DIODES · TSOT-26 | DIODES | TSOT-26 | 1,310 | ₹57.31 · 1,310 in stock | View |
 | KO6401-HF#C489386KEXIN · SOT-23-6 | KEXIN | SOT-23-6 | 2,510 | ₹7.22 · 2,510 in stock | View |
 | TPMN100EPAX#C52817267TECH PUBLIC · SOT-23-6 | TECH PUBLIC | SOT-23-6 | 2,715 | ₹24.09 · 2,715 in stock | View |
 | WST05P06#C5772636Winsok Semicon · SOT-23-6L | Winsok Semicon | SOT-23-6L | 1,795 | ₹32.80 · 1,795 in stock | View |
