MDD(Microdiode Semiconductor)
2N7002KN-Channel 60V 300mA 300mW Surface Mount SOT-23
From
₹2.32
25,99,250 in stock
DIODESDatasheet (PDF)
DMP6350S-7
60V 1.5A 1.17W Surface Mount SOT-23
SOT-23ROHS3 CompliantActive
MOSFET 60V 1.5A SOT-23
- Manufacturer
- DIODES
- Manufacturer part #
- DMP6350S-7
- Store part #
- C155308
- Package / case
- SOT-23
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
110 in stock
#C155308
Stock & price checked 9 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹40.44 | ₹202.20 |
| 50+ | ₹31.53 | ₹1,576.50 |
| 150+ | ₹27.70 | ₹4,155.00 |
| 500+ | ₹22.93 | ₹11,465.00 |
| 3,000+ | ₹19.99 | ₹59,970.00 |
| 6,000+ | ₹18.71 | ₹1,12,260.00 |
5 × ₹40.44
₹202.20
excl. GST
₹238.60 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
DMP6350S-7
₹202.20 for 5 + GST
Specifications
- Output Capacitance(Coss)
- 15pF
- Ciss-Input Capacitance
- 206pF
- Pd - Power Dissipation
- 1.17W
- Operating Temperature
- -55℃~+150℃
- Drain to Source Voltage
- 60V
- Current - Continuous Drain(Id)
- 1.5A
- Reverse Transfer Capacitance (Crss)
- 11pF
- RDS(on)
- 550mΩ@4.5V
- Number
- 1 P-Channel
- Gate Charge(Qg)
- 4.1nC@10V
- Vgs
- ±20V
- Gate Threshold Voltage (Vgs(th))
- 3V
- Type
- P-Channel
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.028 g
Overview
This MOSFET is designed to minimize the on - state resistance (RDS(ON)) and yet maintain superior switching performance, making it ideal for high - efficiency power management applications.
Applications
- Battery Charging
- Power Management Functions
- DC - DC Converters
- Portable Power Adaptors
Key features
- Low On - Resistance
- Low Input Capacitance Fast Switching Speed
- Low Input/Output Leakage
- Totally Lead - Free & Fully RoHS Compliant
- Halogen and Antimony Free. “Green” Device
- Qualified to AEC - Q101 Standards for High Reliability
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | SP60P140T2#C41354820Siliup · SOT-23 | Siliup | SOT-23 | 840 | ₹4.64 · 840 in stock | View |
 | HSS6107#C508450HUASHUO · SOT-23L | HUASHUO | SOT-23L | 10,950 | ₹14.18 · 10,950 in stock | View |
 | SI2309CDS-T1-GE3#C10493VISHAY · SOT-23-3 | VISHAY | SOT-23-3 | 49,145 | ₹23.27 · 49,145 in stock | View |
 | SI2309#C20199353KUU · SOT-23 | KUU | SOT-23 | 1,940 | ₹9.75 · 1,940 in stock | View |
 | CMN1029M#C5203738Cmos · SOT-23-3L | Cmos | SOT-23-3L | 10 | ₹30.53 · 10 in stock | View |
