DMT6015LFVW-7
60V 16mΩ@10V 1 N-channel PowerDI3333-8 Single FETs, MOSFETs RoHS
PowerDI3333-8ROHS3 CompliantActive
- Manufacturer
- DIODES
- Manufacturer part #
- DMT6015LFVW-7
- Store part #
- C6832275
- Package / case
- PowerDI3333-8
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
40 in stock
#C6832275
Stock & price checked 4 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹33.68 | ₹168.40 |
| 50+ | ₹33.14 | ₹1,657.00 |
| 150+ | ₹32.77 | ₹4,915.50 |
| 500+ | ₹32.40 | ₹16,200.00 |
5 × ₹33.68
₹168.40
excl. GST
₹198.71 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 2,000 per reel
DMT6015LFVW-7
₹168.40 for 5 + GST
Specifications
- Operating Temperature
- -55℃~+150℃
- Drain to Source Voltage
- 60V
- Current - Continuous Drain(Id)
- 10A;31.8A
- Ciss-Input Capacitance
- 808pF
- Pd - Power Dissipation
- 2.8W;28.4W
- Reverse Transfer Capacitance (Crss)
- 30pF
- RDS(on)
- 16mΩ@10V
- Number
- 1 N-channel
- Gate Charge(Qg)
- 15.7nC@10V
- Gate Threshold Voltage (Vgs(th))
- 2.5V
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.113 g
Overview
This next-generation MOSFET is designed to minimize on-resistance R<sub>DS(ON)</sub> while maintaining excellent switching performance, making it ideal for high-efficiency power management applications.
Applications
- Backlighting
- Power management
- DC-DC converter
Key features
- 100% unclamped inductive switching (UIS) tested during production — ensures greater reliability and durability in end applications
- Low on-resistance
- Small, thermally efficient package for higher-density end products
- Solderable flanks for optical inspection
- Fully lead-free and fully RoHS compliant
- Halogen- and antimony-free, "green" device
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | TPNTTFS5826NLTAG#C49230910TECH PUBLIC · PDFN-8(3x3) | TECH PUBLIC | PDFN-8(3x3) | 450 | ₹40.93 · 450 in stock | View |
| DMT69M5LFVW-7#C6021921DIODES · PowerDI3333-8 | DIODES | PowerDI3333-8 | 3,870 | ₹84.54 · 3,870 in stock | View | |
 | SIS4608DN-T1-GE3#C6228302VISHAY · PowerPAK1212-8 | VISHAY | PowerPAK1212-8 | 2 | ₹68.02 · 2 in stock | View |
 | DMT69M5LCG-7#C6601881DIODES · VDFN3333-8 | DIODES | VDFN3333-8 | 25 | ₹278.99 · 25 in stock | View |
| NVTFS6H854NTAG#C900536onsemi · WDFN-8(3.3x3.3) | onsemi | WDFN-8(3.3x3.3) | 7 | ₹182.71 · 7 in stock | View | |
