DMT6016LPS-13
N-Channel 60V 32A 26W Surface Mount PowerDI5060-8
PowerDI5060-8ROHS3 CompliantActive
MOSFET N-CH 60V 32A PowerDI5060-8
- Manufacturer
- DIODES
- Manufacturer part #
- DMT6016LPS-13
- Store part #
- C460055
- Package / case
- PowerDI5060-8
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
601 in stock
#C460055
Stock & price checked 10 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹67.22 | ₹67.22 |
| 10+ | ₹53.13 | ₹531.30 |
| 30+ | ₹47.06 | ₹1,411.80 |
| 100+ | ₹39.47 | ₹3,947.00 |
| 500+ | ₹36.00 | ₹18,000.00 |
| 1,000+ | ₹34.04 | ₹34,040.00 |
1 × ₹67.22
₹67.22
excl. GST
₹79.32 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 2,500 per reel
DMT6016LPS-13
₹67.22 for 1 + GST
Specifications
- Operating Temperature
- -55℃~+150℃
- Drain to Source Voltage
- 60V
- Output Capacitance(Coss)
- 282pF
- Current - Continuous Drain(Id)
- 32A
- Ciss-Input Capacitance
- 864pF
- Pd - Power Dissipation
- 26W
- Reverse Transfer Capacitance (Crss)
- 27pF
- RDS(on)
- 15mΩ@10V;24mΩ@4.5V
- Number
- 1 N-channel
- Gate Charge(Qg)
- 8.4nC@4.5V;17nC@10V
- Gate Threshold Voltage (Vgs(th))
- 2.5V
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,500 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.118 g
Overview
This MOSFET is designed to minimize on-resistance R<sub>DS(ON)</sub> while maintaining excellent switching performance, making it ideal for high-efficiency power management applications.
Applications
- Load Switch - Adapter Switch - Laptop
Key features
- 100% UIS tested in production — enhanced reliability and durability in end applications
- Thermally efficient package — lower operating temperature in application
- High conversion efficiency
- Low RDS(ON) — minimized conduction losses
- Low input capacitance
- Fast switching speed
- Package height < 1.1mm — slim and compact applications
- Fully lead-free and fully RoHS compliant
- Halogen and antimony free. "Green" device
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | DMTH6016LPSQ-13#C461127DIODES · PowerDI-5060-8 | DIODES | PowerDI-5060-8 | 3,749 | ₹92.11 · 3,749 in stock | View |
| DMTH6012LPSWQ-13#C5673668DIODES · PowerDI5060-8 | DIODES | PowerDI5060-8 | 2 | ₹347.34 · 2 in stock | View | |
 | RS1L120GNTB#C3278141ROHM · HSOP-8 | ROHM | HSOP-8 | 10 | ₹332.60 · 10 in stock | View |
 | MOT6514G#C29778622MOT · PDFN5X6-8L | MOT | PDFN5X6-8L | 75 | ₹28.56 · 75 in stock | View |
 | E100N8P5HL1#C29781178Existar · PDFN5x6-8 | Existar | PDFN5x6-8 | 4,916 | ₹63.09 · 4,916 in stock | View |
