DIODESDatasheet (PDF)
DMTH10H2M5STLWQ-13
N-Channel 100V 215A 230.8W Surface Mount SOT-363
SOT-363ROHS3 CompliantActive
MOSFET N-CH 100V 215A SOT-363
- Manufacturer
- DIODES
- Manufacturer part #
- DMTH10H2M5STLWQ-13
- Store part #
- C3290119
- Package / case
- SOT-363
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
200 in stock
#C3290119
Stock & price checked 9 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹746.89 | ₹746.89 |
| 10+ | ₹591.43 | ₹5,914.30 |
| 30+ | ₹496.54 | ₹14,896.20 |
| 100+ | ₹416.92 | ₹41,692.00 |
1 × ₹746.89
₹746.89
excl. GST
₹881.33 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 1,500 per reel
DMTH10H2M5STLWQ-13
₹746.89 for 1 + GST
Specifications
- Operating Temperature
- -55℃~+175℃
- Drain to Source Voltage
- 100V
- Output Capacitance(Coss)
- 2.43nF
- Current - Continuous Drain(Id)
- 215A
- Ciss-Input Capacitance
- 8.45nF
- Pd - Power Dissipation
- 230.8W
- Reverse Transfer Capacitance (Crss)
- 17.7pF
- RDS(on)
- 1.68mΩ@10V
- Number
- 1 N-channel
- Gate Charge(Qg)
- 124.4nC@10V
- Gate Threshold Voltage (Vgs(th))
- 4V
- Type
- N-Channel
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 1,500 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.8 g
Overview
This MOSFET is designed to meet the stringent requirements of automotive applications. AEC-Q101 qualified and PPAP supported, it is ideal for motor control, DC-DC converters, and power management.
Applications
- Motor Control - DC-DC Converter - Power Management
Key features
- Rated up to +175°C for high ambient temperature environments
- 100% Unclamped Inductive Switching (UIS) tested during production for enhanced reliability and durability in end applications
- High conversion efficiency
- Low on-state resistance RDS(ON) to minimize conduction losses
- Solderable wings for optical inspection
- Lead-free finish, RoHS compliant
- Halogen- and antimony-free "Green" device
- Suitable for automotive applications requiring specific change control; AEC-Q101 qualified, PPAP capable, manufactured in IATF 16949 certified facilities
