DMTH43M8LFGQ-7
N-Channel 40V 100A 65.2W Surface Mount PowerDI3333-8
PowerDI3333-8ROHS3 CompliantActive
MOSFET N-CH 40V 100A PowerDI3333-8
- Manufacturer
- DIODES
- Manufacturer part #
- DMTH43M8LFGQ-7
- Store part #
- C6540319
- Package / case
- PowerDI3333-8
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,050 in stock
#C6540319
Stock & price checked 8 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹259.74 | ₹259.74 |
| 10+ | ₹217.91 | ₹2,179.10 |
| 30+ | ₹191.68 | ₹5,750.40 |
| 100+ | ₹164.78 | ₹16,478.00 |
| 500+ | ₹152.65 | ₹76,325.00 |
| 1,000+ | ₹147.44 | ₹1,47,440.00 |
1 × ₹259.74
₹259.74
excl. GST
₹306.49 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 2,000 per reel
DMTH43M8LFGQ-7
₹259.74 for 1 + GST
Specifications
- Operating Temperature
- -55℃~+175℃
- Drain to Source Voltage
- 40V
- Output Capacitance(Coss)
- 904pF
- Current - Continuous Drain(Id)
- 100A
- Ciss-Input Capacitance
- 2.798nF
- Pd - Power Dissipation
- 65.2W
- Reverse Transfer Capacitance (Crss)
- 88pF
- RDS(on)
- 2.3mΩ@10V
- Number
- 1 N-channel
- Gate Charge(Qg)
- 40.1nC@10V
- Gate Threshold Voltage (Vgs(th))
- 1.5V
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.154 g
Overview
This MOSFET is designed to meet the stringent requirements of automotive applications. It complies with AEC-Q101 and is supported by PPAP documentation, making it ideal for: - Motor control - DC-DC converters - Power management
Applications
- Motor Control
- DC-DC Converter
- Power Management
Key features
- Rated temperature up to +175°C, suitable for high-temperature environments
- 100% unclamped inductive switching tested for enhanced reliability and durability in end applications
- Low on-resistance RDS(ON) for minimized conduction losses
- Excellent gate-drain charge QGD × RDS(ON) figure of merit (FOM)
- Lead-free surface finish, RoHS compliant
- Halogen- and antimony-free, "green" device
