EA2224
Buck-Boost Switching Regulator IC Adjustable 2.8V~5.5V 1 Output 3A TDFN-14-EP(3x4)
TDFN-14-EP(3x4)ROHS CompliantActive
High Efficiency Single Inductor Auto Buck-Boost Converter
- Manufacturer
- Everanalog IC design
- Manufacturer part #
- EA2224
- Store part #
- C47866880
- Package / case
- TDFN-14-EP(3x4)
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,527 in stock
#C47866880
Stock & price checked 4 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹75.83 | ₹75.83 |
| 10+ | ₹66.92 | ₹669.20 |
| 30+ | ₹62.58 | ₹1,877.40 |
| 100+ | ₹58.24 | ₹5,824.00 |
| 500+ | ₹55.62 | ₹27,810.00 |
| 1,000+ | ₹54.32 | ₹54,320.00 |
1 × ₹75.83
₹75.83
excl. GST
₹89.48 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
EA2224
₹75.83 for 1 + GST
Specifications
- Operating Temperature
- -40℃~+85℃@(TA)
- Function
- Buck-Boost
- Frequency - Switching
- 2.2MHz~2.6MHz
- Number of Outputs
- 1
- Features
- Cycle-by-cycle current limiting;Overcurrent Protection;Frequency synchronization;Light load efficient mode;Operating status indication;Load disconnect
- Topology
- Buck-Boost
- Output Type
- Adjustable
- Operating Voltage
- 2.7V~5.5V
- Switch tube (built-in/external)
- Built-in
- Output Voltage
- 2.8V~5.5V
- Output Current
- 3A
- Quiescent Current
- 40uA
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.153 g
Overview
EA2224 is a high-efficiency single-inductor buck-boost converter capable of delivering up to 4A of load current. It automatically transitions between buck mode and boost mode. The EA2224 operates at 2.4MHz and can be synchronized to an external frequency between 2.2MHz and 2.6MHz. At light loads, the DC/DC converter operates in pulse-skipping mode. The power-saving mode can be disabled to force the EA2224 into forced PWM mode. The output voltage can be programmed via an external resistive voltage divider or internally fixed at 3.3V. During shutdown, the load is disconnected from VIN. The EA2224 is available in a TDFN3X4-14 package.
Applications
- Mobile handheld devices
- Smartphones
Key features
- 2.7V ~ 5.5V input voltage operating range
- Adjustable output voltage from 2.8V to 5.5V
- DC/DC converter with up to 96% efficiency
- 3.3V/3A output current when VIN > 3.6V
- Automatic switching between buck and boost modes
- Pulse skipping mode for improved light-load efficiency
- Configurable for lower quiescent current DC/DC operation at light load
- Fixed 2.4MHz frequency with synchronization capability
- Internal soft-start
- Built-in cycle-by-cycle current limiting and overvoltage protection
- Built-in thermal shutdown
- Power Good function
- TDFN3X4-14 package
