PANASONIC

EEEFN1V470V

47uF ±20% 35V Aluminum Electrolytic Capacitors 2000hrs@105℃

SMD,D6.3xL5.8mmROHS3 CompliantActive

CAP ALUM 47uF ±20% 35V SMD

Manufacturer: PANASONIC
Manufacturer part #: EEEFN1V470V
Store part #: C497599
Package / case: SMD,D6.3xL5.8mm
Category: Aluminum Electrolytic Capacitors
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

650 in stock

#C497599

Stock & price checked 8 days ago

Quantity	Unit price	Pack price
1+	₹82.89	₹82.89
10+	₹67.70	₹677.00
30+	₹60.32	₹1,809.60
100+	₹52.72	₹5,272.00
500+	₹48.17	₹24,085.00
1,000+	₹46.00	₹46,000.00

Quantity (min 1)

1 × ₹82.89

₹82.89

excl. GST

₹97.81 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 15-18 working days
GST invoice with every order
Standard pack: 1,000 per reel

EEEFN1V470V

₹82.89 for 1 + GST

Need this with the rest of your board? Upload the BOM — we price every line.Upload BOM

Specifications

Tolerance: ±20%
Voltage Rating: 35V
Lifetime: 2000hrs@105℃
Capacitance: 47uF
Ripple Current: 240mA@100kHz
Polarity type: Polarized
Operating Temperature: -55℃~+105℃
Equivalent Series Resistance(ESR): 360mΩ@100kHz

Packaging & compliance

RoHS: ROHS3 Compliant
Lifecycle: Active
ECCN: EAR99
Packaging: Tape & Reel (TR)
Standard pack: 1,000 / Reel
Sold per: Piece
Minimum order: 1
Unit weight: 0.718 g

Overview

SMD aluminum electrolytic capacitors. FN series 6.3V to 50V supports high-temperature lead-free reflow soldering; 63V to 100V supports standard lead-free reflow soldering.

Key features

Durability: 2000 hours at 105°C
Wide voltage range: 6.3V to 100V
High capacitance: 20% to 80% higher than FK series
Vibration-proof products available on request (diameter ≥6.3mm, guaranteed 30G)
AEC-Q200 compliant
RoHS compliant

Alternatives

Similar parts — check the datasheet before substituting.

	Manufacturer	Package	Stock	Price from (excl. GST)	Action
UCD1V470MCL1GS#C445448Nichicon · SMD,D6.3xL5.8mm	Nichicon	SMD,D6.3xL5.8mm	1,575	₹23.59 · 1,575 in stock	View
EEEFN1V470P#C494838PANASONIC · SMD,D6.3xL5.8mm	PANASONIC	SMD,D6.3xL5.8mm	80	₹23.44 · 80 in stock	View
EEEFP1V470AP#C401754PANASONIC · SMD,D6.3xL5.8mm	PANASONIC	SMD,D6.3xL5.8mm	6,935	₹31.41 · 6,935 in stock	View
UUD1V470MCL1GS#C225869Nichicon · SMD,D6.3xL5.8mm	Nichicon	SMD,D6.3xL5.8mm	520	₹20.45 · 520 in stock	View
UCL1V470MCL1GS#C251012Nichicon · SMD,D6.3xL5.8mm	Nichicon	SMD,D6.3xL5.8mm	285	₹36.95 · 285 in stock	View
