ESD5111PFCT5G
5.5VC 6.5VC Clamp ESD DIODE WLCSP-2(0.3x0.6)
ESD DIODE 3.3VWM 5.5VC 6.5VC WLCSP-2(0.3x0.6)
- Manufacturer
- onsemi
- Manufacturer part #
- ESD5111PFCT5G
- Store part #
- C896704
- Package / case
- WLCSP-2(0.3x0.6)
- Category
- TVS Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
560 in stock
#C896704
Stock & price checked 8 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 10+ | ₹6.95 | ₹69.50 |
| 100+ | ₹5.53 | ₹553.00 |
| 300+ | ₹4.82 | ₹1,446.00 |
| 1,000+ | ₹4.29 | ₹4,290.00 |
| 5,000+ | ₹3.36 | ₹16,800.00 |
| 10,000+ | ₹3.15 | ₹31,500.00 |
10 × ₹6.95
₹69.50
excl. GST
₹82.01 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 10,000 per reel
ESD5111PFCT5G
₹69.50 for 10 + GST
Specifications
- Clamping Voltage
- 5.5V;6.5V
- Operating Temperature
- -55℃~+125℃
- Number of Channels
- 1
- Voltage - Breakdown
- 5V
- type
- ESD
- Polarity
- Bidirectional
- Reverse Leakage Current (Ir)
- 100nA
- Reverse Stand-Off Voltage (Vrwm)
- 3.3V
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 10,000 / Reel
- Sold per
- Piece
- Minimum order
- 10 (multiples of 10)
- Unit weight
- 0.015 g
Overview
The ESD51x1 Series is designed to protect voltage sensitive components from ESD. Excellent clamping capability, low leakage, and fast response time provide best in class protection on designs that are exposed to ESD. Because of its small size, it is suited for use in smartphone, smart-watch, or many other portable / wearable applications where board space comes at a premium.
Applications
- smartphone
- smart-watch
- portable / wearable applications
Key features
- Low Capacitance (5 pF Max, I/O to GND)
- Small Body Outline Dimensions
- 01005 Size: 0.435 x 0.23 mm
- 0201 Size: 0.6 x 0.3 mm
- Protection for the Following IEC Standards: IEC 61000−4−2 (Level 4)
- Low ESD Clamping Voltage
- These Devices are Pb−Free, Halogen Free/BFR Free and are RoHS Compliant
