FDS4675
P-Channel 40V 11A 2.4W Surface Mount SO-8
SO-8ROHS3 CompliantActive
MOSFET P-CH 40V 11A SO-8
- Manufacturer
- onsemi
- Manufacturer part #
- FDS4675
- Store part #
- C236902
- Package / case
- SO-8
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
103 in stock
#C236902
Stock & price checked 11 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹213.59 | ₹213.59 |
| 10+ | ₹178.35 | ₹1,783.50 |
| 30+ | ₹159.00 | ₹4,770.00 |
| 100+ | ₹122.25 | ₹12,225.00 |
| 500+ | ₹112.46 | ₹56,230.00 |
| 1,000+ | ₹108.10 | ₹1,08,100.00 |
1 × ₹213.59
₹213.59
excl. GST
₹252.04 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 2,500 per reel
FDS4675
₹213.59 for 1 + GST
Specifications
- Output Capacitance(Coss)
- 622pF
- Ciss-Input Capacitance
- 4.35nF
- Pd - Power Dissipation
- 2.4W
- Operating Temperature
- -55℃~+175℃
- Drain to Source Voltage
- 40V
- Current - Continuous Drain(Id)
- 11A
- Reverse Transfer Capacitance (Crss)
- 290pF
- RDS(on)
- 17mΩ@4.5V
- Number
- 1 P-Channel
- Gate Charge(Qg)
- 56nC@4.5V
- Vgs
- ±20V
- Gate Threshold Voltage (Vgs(th))
- 3V
- Type
- P-Channel
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,500 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.114 g
Overview
This P-Channel MOSFET is a rugged gate version of advanced PowerTrench process. It has been optimized for power management applications requiring a wide range of gave drive voltage ratings (4.5V - 20V).
Applications
- Power management
- Load switch
- Battery protection
Key features
- –11 A, –40 V, RDS(ON)=0.013 Ω @ VGS=-10 V, RDS(ON)=0.017 Ω @ VGS=-4.5 V
- Fast switching speed
- High performance trench technology for extremely low RDS(ON)
- High power and current handling capability
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | SP40P08P8#C41355191Siliup · SOP-8L | Siliup | SOP-8L | 3,990 | ₹19.18 · 3,990 in stock | View |
 | LWP4015CS#C54740936Lewa Micro · SOP-8 | Lewa Micro | SOP-8 | 3,990 | ₹33.35 · 3,990 in stock | View |
 | HSM4115#C700984HUASHUO · SOP-8 | HUASHUO | SOP-8 | 680 | ₹36.92 · 680 in stock | View |
 | SP40P12P8#C41355196Siliup · SOP-8L | Siliup | SOP-8L | 3,970 | ₹25.76 · 3,970 in stock | View |
 | IRF7240TRPBF#C5197351TECH PUBLIC · SOP-8 | TECH PUBLIC | SOP-8 | 605 | ₹56.45 · 605 in stock | View |
