VBsemi ElecDatasheet (PDF)
FDS8958A-NL-VB
30V 6.8A 2W 1 N-Channel + 1 P-Channel SOP-8 Single FETs, MOSFETs RoHS
SOP-8ROHS CompliantActive
MOSFET N/P-CH 30V 6.8A SOP-8
- Manufacturer
- VBsemi Elec
- Manufacturer part #
- FDS8958A-NL-VB
- Store part #
- C7525026
- Package / case
- SOP-8
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
20 in stock
#C7525026
Stock & price checked 7 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹52.59 | ₹52.59 |
| 10+ | ₹41.29 | ₹412.90 |
| 30+ | ₹36.51 | ₹1,095.30 |
| 100+ | ₹30.43 | ₹3,043.00 |
| 500+ | ₹27.82 | ₹13,910.00 |
| 1,000+ | ₹26.08 | ₹26,080.00 |
1 × ₹52.59
₹52.59
excl. GST
₹62.06 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 4,000 per reel
FDS8958A-NL-VB
₹52.59 for 1 + GST
Specifications
- Operating Temperature
- -55℃~+150℃
- Drain to Source Voltage
- 30V
- Current - Continuous Drain(Id)
- 6.8A
- Ciss-Input Capacitance
- 510pF
- Pd - Power Dissipation
- 2W
- Reverse Transfer Capacitance (Crss)
- 33pF
- Number
- 1 N-Channel + 1 P-Channel
- Gate Charge(Qg)
- 5.8nC@10V
- Gate Threshold Voltage (Vgs(th))
- 1V
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 4,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.123 g
Overview
Applications
- Motor Drive - Power Bank
Key features
- Compliant with halogen-free standard as defined by IEC 61249-2-21
- Trench power MOSFET
- 100% Rg and UIS tested
- Compliant with RoHS Directive 2002/95/EC
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | FDS8333C-NL-VB#C7463644VBsemi Elec · SO-8 | VBsemi Elec | SO-8 | 15 | ₹56.53 · 15 in stock | View |
 | C3028LD-VB#C709927VBsemi Elec · SO-8 | VBsemi Elec | SO-8 | 19 | ₹52.73 · 19 in stock | View |
 | STC4516S8RG-VB#C2680801VBsemi Elec · SO-8 | VBsemi Elec | SO-8 | 50 | ₹52.10 · 50 in stock | View |
 | HAT3004R-VB#C5179580VBsemi Elec · SO-8 | VBsemi Elec | SO-8 | 30 | ₹59.01 · 30 in stock | View |
 | FW342-TL-E-VB#C5441225VBsemi Elec · SO-8 | VBsemi Elec | SO-8 | 16 | ₹52.10 · 16 in stock | View |
