FDV304P
P-Channel 30V 1.5A 1.11W Surface Mount SOT-23
SOT-23RoHSActive
MOSFET P-CH 30V 1.5A SOT-23
- Manufacturer
- MSKSEMI
- Manufacturer part #
- FDV304P
- Store part #
- C5343304
- Package / case
- SOT-23
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,485 in stock
#C5343304
Stock & price checked 7 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹13.47 | ₹67.35 |
| 50+ | ₹10.65 | ₹532.50 |
| 150+ | ₹9.23 | ₹1,384.50 |
| 500+ | ₹8.18 | ₹4,090.00 |
| 3,000+ | ₹7.04 | ₹21,120.00 |
| 6,000+ | ₹6.62 | ₹39,720.00 |
5 × ₹13.47
₹67.35
excl. GST
₹79.47 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
FDV304P
₹67.35 for 5 + GST
Specifications
- Operating Temperature
- -55℃~+150℃
- Drain to Source Voltage
- 30V
- Output Capacitance(Coss)
- 85pF
- Current - Continuous Drain(Id)
- 1.5A
- Ciss-Input Capacitance
- 810pF
- Pd - Power Dissipation
- 1.11W
- Reverse Transfer Capacitance (Crss)
- 50pF
- RDS(on)
- 900mΩ@10V
- Number
- 1 P-Channel
- Gate Charge(Qg)
- 12.5nC@10V
- Gate Threshold Voltage (Vgs(th))
- 900mV
- Type
- P-Channel
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.035 g
Overview
These P-channel enhancement-mode power MOSFETs are fabricated using trench DMOS technology. This advanced technology is specifically designed to minimize on-resistance, deliver superior switching performance, and withstand high-energy pulses in avalanche and commutation modes. These devices are ideal for high-efficiency, fast-switching applications.
Applications
- Laptop - Load Switch - Battery Protection - Handheld Instruments
Key features
- -30V, -1.5A, R DS(ON) = 900mΩ at VGS = -10V
- Fast switching
- Green device available
- Suitable for -2.5V gate drive applications
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | AO3401A#C5379091MSKSEMI · SOT-23-3L | MSKSEMI | SOT-23-3L | 3,510 | ₹7.12 · 3,510 in stock | View |
 | AO3401MI-MS#C2847031MSKSEMI · SOT-23-3L | MSKSEMI | SOT-23-3L | 2,790 | ₹9.63 · 2,790 in stock | View |
 | WPM3407-MS#C2836379MSKSEMI · SOT-23 | MSKSEMI | SOT-23 | 1,260 | ₹8.48 · 1,260 in stock | View |
 | SI2309CDS-T1-GE3-MS#C5343293MSKSEMI · SOT-23 | MSKSEMI | SOT-23 | 320 | ₹9.57 · 320 in stock | View |
 | SI2309CDS-T1-MS#C5278012MSKSEMI · SOT-23 | MSKSEMI | SOT-23 | On request | ₹11.26 · 0 in stock | View |
