FQPF16N60-VB
N-Channel 650V 9A 123W Through Hole TO-220AB
TO-220ABRoHSActive
MOSFET N-CH 650V 9A TO-220AB
- Manufacturer
- VBsemi Elec
- Manufacturer part #
- FQPF16N60-VB
- Store part #
- C19190272
- Package / case
- TO-220AB
- Category
- Single FETs, MOSFETs
- Packaging
- Tube-packed
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
18 in stock
#C19190272
Stock & price checked 8 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹228.46 | ₹228.46 |
| 10+ | ₹190.42 | ₹1,904.20 |
| 50+ | ₹169.81 | ₹8,490.50 |
| 100+ | ₹146.22 | ₹14,622.00 |
| 500+ | ₹135.81 | ₹67,905.00 |
| 1,000+ | ₹131.12 | ₹1,31,120.00 |
1 × ₹228.46
₹228.46
excl. GST
₹269.58 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 50 per tube
FQPF16N60-VB
₹228.46 for 1 + GST
Specifications
- Operating Temperature
- -55℃~+150℃
- Drain to Source Voltage
- 650V
- Output Capacitance(Coss)
- 25pF
- Current - Continuous Drain(Id)
- 9A
- Ciss-Input Capacitance
- 360pF
- Pd - Power Dissipation
- 123W
- Reverse Transfer Capacitance (Crss)
- 12pF
- RDS(on)
- 500mΩ@10V
- Number
- 1 N-channel
- Gate Charge(Qg)
- 25nC@10V
- Gate Threshold Voltage (Vgs(th))
- 4V
- Type
- N-Channel
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tube-packed
- Standard pack
- 50 / Tube
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 3.99 g
Overview
Applications
- Server and telecom power supplies
- Switch mode power supplies (SMPS)
- Power factor correction power supplies (PFC)
- Lighting - High-intensity discharge (HID) - Fluorescent ballast lighting
- Industrial
Key features
- Low figure of merit (FOM) Ron × Qg
- Low input capacitance (Ciss)
- Reduced switching and conduction losses
- Ultra-low gate charge (Qg)
- Avalanche energy rated (UIS)
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | 12N60 TO220-VB#C20417635VBsemi Elec · TO-220AB | VBsemi Elec | TO-220AB | 8 | ₹225.81 · 8 in stock | View |
 | 6R600P TO220-VB#C20417646VBsemi Elec · TO-220AB | VBsemi Elec | TO-220AB | 10 | ₹225.81 · 10 in stock | View |
 | STP9NM50N-VB#C20626324VBsemi Elec · TO-220AB | VBsemi Elec | TO-220AB | 8 | ₹225.81 · 8 in stock | View |
 | BUK437-500A-VB#C20755149VBsemi Elec · TO-220AB | VBsemi Elec | TO-220AB | 10 | ₹225.81 · 10 in stock | View |
 | FDP12N50NZ-VB#C20755496VBsemi Elec · TO-220AB | VBsemi Elec | TO-220AB | 1 | ₹225.81 · 1 in stock | View |
