HAZ1013-04F
8VC 1.8VC Clamp 4A@8/20us Ipp ESD DIODE DFN2510-10L
ESD DIODE 3.3VWM 8VC 1.8VC DFN2510-10L
- Manufacturer
- HXY MOSFET
- Manufacturer part #
- HAZ1013-04F
- Store part #
- C22439950
- Package / case
- DFN2510-10L
- Category
- TVS Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
320 in stock
#C22439950
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 10+ | ₹9.31 | ₹93.10 |
| 100+ | ₹7.37 | ₹737.00 |
| 300+ | ₹6.39 | ₹1,917.00 |
| 3,000+ | ₹5.66 | ₹16,980.00 |
| 6,000+ | ₹5.08 | ₹30,480.00 |
| 9,000+ | ₹4.79 | ₹43,110.00 |
10 × ₹9.31
₹93.10
excl. GST
₹109.86 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
HAZ1013-04F
₹93.10 for 10 + GST
Specifications
- Clamping Voltage
- 8V;1.8V
- Operating Temperature
- -40℃~+125℃
- Peak Pulse Current (Ipp)
- 4A@8/20us
- Peak Pulse Power Dissipation (Ppp)
- 70W@8/20us
- Voltage - Breakdown
- 5.6V
- Number of Channels
- Four channels
- type
- ESD
- Reverse Leakage Current (Ir)
- 1uA
- Reverse Stand-Off Voltage (Vrwm)
- 3.3V
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 10 (multiples of 10)
- Unit weight
- 0.017 g
Overview
HAZ1013 - 04F is a 4-channel ultra-low capacitance rail-clamp ESD protection diode array. Each channel consists of a diode pair that steers positive or negative ESD current to the positive or negative rail. A Zener diode is integrated between the positive and negative supply rails. In a typical application, the negative rail pin (designated as GND) is connected to system ground. Positive ESD current is steered to ground through the ESD diodes and Zener diode, and the positive ESD voltage is clamped to the Zener voltage. The package is DFN2510-10L.
Key features
- 4-channel ESD protection
- ESD protection per IEC61000-4-2 Level 4
- ±15kV air discharge
- ±10kV contact discharge
- Channel I/O to GND capacitance: 0.4pF max
- Channel I/O to I/O capacitance: 0.6pF max
- Low clamping voltage
- Low operating voltage
- Improved Zener structure
- Optimized package for high-speed data line PCB layout
- RoHS compliant and halogen-free
