HE9427
Step-down type 500kHz Adjustable 3A ESOP-8 Voltage Regulators - DC DC Switching Regulators RoHS
ESOP-8ROHS CompliantActive
30V 3A Synchronous Step-Down Converter
- Manufacturer
- HEERMICR
- Manufacturer part #
- HE9427
- Store part #
- C41366984
- Package / case
- ESOP-8
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,735 in stock
#C41366984
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹31.86 | ₹159.30 |
| 50+ | ₹24.74 | ₹1,237.00 |
| 150+ | ₹21.68 | ₹3,252.00 |
| 500+ | ₹17.89 | ₹8,945.00 |
| 3,000+ | ₹16.63 | ₹49,890.00 |
| 6,000+ | ₹15.62 | ₹93,720.00 |
5 × ₹31.86
₹159.30
excl. GST
₹187.97 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
HE9427
₹159.30 for 5 + GST
Specifications
- Operating Temperature
- -40℃~+85℃
- Function
- Step-down type
- Frequency - Switching
- 500kHz
- Number of Outputs
- 1
- Features
- Cycle-by-cycle current limiting;Hiccup current limiting;Overcurrent Protection
- Output Type
- Adjustable
- Topology
- Buck
- Operating Voltage
- 6V~30V
- Switch tube (built-in/external)
- Built-in
- Output Current
- 3A
- Quiescent Current
- 400uA
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 3 (168 hours)
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.203 g
Overview
A high frequency, synchronous, rectified, step-down, switch-mode converter with internal power MOSFETs. It offers a very compact solution to achieve a 4A peak output current over a wide input supply range, with excellent load and line regulation. Requires a minimal number of readily available, external components and is available in a space saving ESOP8 package.
Applications
- CCTV Camera
- Battery Charger
- Flat-Panel Television and Monitor
- Distributed Power Systems
Key features
- Wide 6V to 30V Operating Input Range
- 3A Continuous Output Current
- Fixed 500KHz Switching Frequency
- No Schottky Diode Required
- Short Protection with Hiccup-Mode
- Built-in Over Current Limit
- Built-in Over Voltage Protection
- Internal Soft start
- Output Adjustable from 0.925V
- Integrated internal compensation
- Thermal Shutdown
- Available in ESOP8 Package
- -40°C to +85°C Temperature Range
