HIPD650P06NM
P-Channel 60V 20A 25W Surface Mount TO-252-2L
TO-252-2LRoHSActive
MOSFET P-CH 60V 20A TO-252-2L
- Manufacturer
- HXY MOSFET
- Manufacturer part #
- HIPD650P06NM
- Store part #
- C42401360
- Package / case
- TO-252-2L
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
102 in stock
#C42401360
Stock & price checked 9 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹132.91 | ₹132.91 |
| 10+ | ₹109.07 | ₹1,090.70 |
| 30+ | ₹97.13 | ₹2,913.90 |
| 100+ | ₹85.21 | ₹8,521.00 |
| 500+ | ₹78.28 | ₹39,140.00 |
| 1,000+ | ₹74.59 | ₹74,590.00 |
1 × ₹132.91
₹132.91
excl. GST
₹156.83 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 2,500 per reel
HIPD650P06NM
₹132.91 for 1 + GST
Specifications
- Operating Temperature
- -55℃~+175℃
- Configuration
- Standalone
- Drain to Source Voltage
- 60V
- Output Capacitance(Coss)
- 100pF
- Current - Continuous Drain(Id)
- 20A
- Ciss-Input Capacitance
- 585pF
- Pd - Power Dissipation
- 25W
- Reverse Transfer Capacitance (Crss)
- 85pF
- RDS(on)
- 48mΩ@10V
- Number
- 1 P-Channel
- Gate Charge(Qg)
- 6.1nC@4.5V
- Gate Threshold Voltage (Vgs(th))
- 2.5V
- Type
- P-Channel
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,500 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.378 g
