HT7330-1-MS
Linear Voltage Regulator IC Positive Fixed 1 Output 300mA SOT-89
SOT-89RoHSActive
Low Dropout Linear Regulator
- Manufacturer
- MSKSEMI
- Manufacturer part #
- HT7330-1-MS
- Store part #
- C7434185
- Package / case
- SOT-89
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
840 in stock
#C7434185
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹10.44 | ₹52.20 |
| 50+ | ₹8.26 | ₹413.00 |
| 150+ | ₹7.16 | ₹1,074.00 |
| 1,000+ | ₹6.34 | ₹6,340.00 |
| 2,000+ | ₹5.69 | ₹11,380.00 |
| 5,000+ | ₹5.36 | ₹26,800.00 |
5 × ₹10.44
₹52.20
excl. GST
₹61.60 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 1,000 per reel
HT7330-1-MS
₹52.20 for 5 + GST
Specifications
- Output Voltage
- 3V
- Number of Outputs
- 1
- Operating Temperature
- -35℃~+80℃@(Ta)
- Supply Current (Iq)
- 1.5uA
- Output Configuration
- Positive
- Output Current
- 300mA
- Operating Voltage
- 24V
- Output Type
- Fixed
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 1,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.149 g
Overview
HT73XX-1-MS is a low dropout linear regulator using CMOS technology. Output current is 300mA with a maximum allowable input voltage of 24V. Several fixed output voltages are available, ranging from 3.0V to 5.0V. CMOS technology ensures low dropout voltage and low quiescent current characteristics.
Applications
- Various power supply equipment
- Communication equipment
- Audio and video equipment
Key features
- Low power consumption
- Low dropout
- Low temperature coefficient
- Operating voltage up to 24V
- Quiescent current 1.5μA
- Output voltage accuracy: ±2%
- Output current: 300mA
- Package types: SOT23-3, SOT89
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | HT7330-3-MS#C30197513MSKSEMI · SOT-89-3 | MSKSEMI | SOT-89-3 | 505 | ₹19.73 · 505 in stock | View |
 | HT7330-2-MS#C30197516MSKSEMI · SOT-89 | MSKSEMI | SOT-89 | 860 | ₹24.65 · 860 in stock | View |
