VBsemi ElecDatasheet (PDF)
IPD90N04S3-04-VB
N-Channel 40V 85A 3.13W Surface Mount TO-252
TO-252RoHSActive
MOSFET N-CH 40V 85A TO-252
- Manufacturer
- VBsemi Elec
- Manufacturer part #
- IPD90N04S3-04-VB
- Store part #
- C7429001
- Package / case
- TO-252
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
66 in stock
#C7429001
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹82.32 | ₹82.32 |
| 10+ | ₹66.19 | ₹661.90 |
| 30+ | ₹58.24 | ₹1,747.20 |
| 100+ | ₹50.27 | ₹5,027.00 |
| 500+ | ₹45.67 | ₹22,835.00 |
| 1,000+ | ₹43.16 | ₹43,160.00 |
1 × ₹82.32
₹82.32
excl. GST
₹97.14 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 2,500 per reel
IPD90N04S3-04-VB
₹82.32 for 1 + GST
Specifications
- Operating Temperature
- -55℃~+150℃
- Drain to Source Voltage
- 40V
- Output Capacitance(Coss)
- 550pF
- Current - Continuous Drain(Id)
- 85A
- Ciss-Input Capacitance
- 2.38nF
- Pd - Power Dissipation
- 3.13W
- Reverse Transfer Capacitance (Crss)
- 250pF
- RDS(on)
- 5mΩ@10V;6.5mΩ@4.5V
- Number
- 1 N-channel
- Gate Charge(Qg)
- 80nC@10V
- Gate Threshold Voltage (Vgs(th))
- 2.5V
- Type
- N-Channel
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,500 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.388 g
Overview
Applications
- Synchronous Rectification Power Supplies
- N-Channel MOSFET
Key features
- TrenchFET Power MOSFET 100 % Rg and UIS Tested
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | APM4018NUC-TRL-VB#C29779086VBsemi Elec · TO-252 | VBsemi Elec | TO-252 | 20 | ₹82.56 · 20 in stock | View |
 | VBE1405#C416254VBsemi Elec · TO-252 | VBsemi Elec | TO-252 | 674 | ₹106.87 · 674 in stock | View |
 | 50N04-VB#C4355077VBsemi Elec · TO-252 | VBsemi Elec | TO-252 | 84 | ₹85.92 · 84 in stock | View |
 | APM4010NUC-TRL-VB#C5438926VBsemi Elec · TO-252 | VBsemi Elec | TO-252 | 50 | ₹89.04 · 50 in stock | View |
 | IRFR4104TRPBF-VB#C558163VBsemi Elec · TO-252 | VBsemi Elec | TO-252 | 190 | ₹100.11 · 190 in stock | View |
