InfineonDatasheet (PDF)
IPP019N08NF2SAKMA1
3.8W 80V 191A 1.9mΩ@10V 1 N-channel N-Channel TO-220-3 Single FETs, MOSFETs RoHS
TO-220-3ROHS3 CompliantActive
- Manufacturer
- Infineon
- Manufacturer part #
- IPP019N08NF2SAKMA1
- Store part #
- C5311583
- Package / case
- TO-220-3
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
4 in stock
#C5311583
Stock & price checked 4 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹246.86 | ₹246.86 |
| 10+ | ₹241.21 | ₹2,412.10 |
| 30+ | ₹237.52 | ₹7,125.60 |
| 100+ | ₹233.60 | ₹23,360.00 |
1 × ₹246.86
₹246.86
excl. GST
₹291.29 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 15,000 per reel
IPP019N08NF2SAKMA1
₹246.86 for 1 + GST
Specifications
- Output Capacitance(Coss)
- 1.4nF
- Ciss-Input Capacitance
- 8.7nF
- Pd - Power Dissipation
- 3.8W
- Drain to Source Voltage
- 80V
- Operating Temperature
- -55℃~+175℃
- Current - Continuous Drain(Id)
- 191A
- Reverse Transfer Capacitance (Crss)
- 61pF
- RDS(on)
- 1.9mΩ@10V
- Number
- 1 N-channel
- Gate Charge(Qg)
- 124nC@10V
- Vgs
- ±20V
- Gate Threshold Voltage (Vgs(th))
- 3.8V
- Type
- N-Channel
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 15,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 2.97 g
Overview
Applications
- Load/power switch
- Interface switch
- Logic level translation
Key features
- Optimized for a wide range of applications
- N-channel, normal level
- 100% avalanche tested
- Lead-free lead plating; RoHS compliant
- Halogen-free per IEC61249-2-21
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | NCEP028N85#C2686639NCE · TO-220 | NCE | TO-220 | 88 | ₹264.16 · 88 in stock | View |
 | IPP016N08NF2SAKMA1#C5222901Infineon · TO-220-3 | Infineon | TO-220-3 | 260 | ₹432.89 · 260 in stock | View |
 | TK100E10N1,S1X(S#C396029TOSHIBA · TO-220 | TOSHIBA | TO-220 | 1,959 | ₹214.43 · 1,959 in stock | View |
 | LWT1H02H8#C54221165Lewa Micro · TO-220AB | Lewa Micro | TO-220AB | 97 | ₹130.63 · 97 in stock | View |
 | TK100E08N1,S1X(S#C396033TOSHIBA · TO-220 | TOSHIBA | TO-220 | 2,324 | ₹164.70 · 2,324 in stock | View |
