IRF40R207
N-Channel 40V 56A 83W Surface Mount TO-252
TO-252ROHS3 CompliantActive
MOSFET N-CH 40V 56A TO-252
- Manufacturer
- Infineon
- Manufacturer part #
- IRF40R207
- Store part #
- C3007638
- Package / case
- TO-252
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
140 in stock
#C3007638
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹87.62 | ₹87.62 |
| 10+ | ₹70.89 | ₹708.90 |
| 30+ | ₹62.62 | ₹1,878.60 |
| 100+ | ₹54.36 | ₹5,436.00 |
| 500+ | ₹49.36 | ₹24,680.00 |
| 1,000+ | ₹46.75 | ₹46,750.00 |
1 × ₹87.62
₹87.62
excl. GST
₹103.39 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 2,000 per reel
IRF40R207
₹87.62 for 1 + GST
Specifications
- Output Capacitance(Coss)
- 340pF
- Ciss-Input Capacitance
- 2.11nF
- Pd - Power Dissipation
- 83W
- Operating Temperature
- -55℃~+175℃
- Drain to Source Voltage
- 40V
- Current - Continuous Drain(Id)
- 56A
- Reverse Transfer Capacitance (Crss)
- 220pF
- RDS(on)
- 5.1mΩ@10V
- Number
- 1 N-channel
- Gate Charge(Qg)
- 68nC@10V
- Vgs
- ±20V
- Gate Threshold Voltage (Vgs(th))
- 3.9V
- Type
- N-Channel
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.52 g
Overview
Applications
- Brushed Motor drive applications
- BLDC Motor drive applications
- Battery powered circuits
- Half-bridge and full-bridge topologies
- Synchronous rectifier applications
- Resonant mode power supplies
- OR-ing and redundant power switches
- DC/DC and AC/DC converters
- DC/AC Inverters
Key features
- Improved Gate, Avalanche and Dynamic dV/dt Ruggedness
- Fully Characterized Capacitance and Avalanche SOA
- Enhanced body diode dV/dt and dI/dt Capability
- Lead-Free
- RoHS Compliant, Halogen-Free
