TECH PUBLICDatasheet (PDF)
IRF5803TRPBF-TP
P-Channel 40V 4A 1.6W Surface Mount SOT-23-6
SOT-23-6RoHSActive
MOSFET P-CH 40V 4A SOT-23-6
- Manufacturer
- TECH PUBLIC
- Manufacturer part #
- IRF5803TRPBF-TP
- Store part #
- C22435109
- Package / case
- SOT-23-6
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,740 in stock
#C22435109
Stock & price checked 7 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹19.06 | ₹95.30 |
| 50+ | ₹14.90 | ₹745.00 |
| 150+ | ₹13.11 | ₹1,966.50 |
| 500+ | ₹10.88 | ₹5,440.00 |
| 3,000+ | ₹9.88 | ₹29,640.00 |
| 6,000+ | ₹9.29 | ₹55,740.00 |
5 × ₹19.06
₹95.30
excl. GST
₹112.45 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
IRF5803TRPBF-TP
₹95.30 for 5 + GST
Specifications
- Operating Temperature
- -55℃~+150℃
- Drain to Source Voltage
- 40V
- Output Capacitance(Coss)
- 122pF
- Current - Continuous Drain(Id)
- 4A
- Ciss-Input Capacitance
- 833pF
- Pd - Power Dissipation
- 1.6W
- Reverse Transfer Capacitance (Crss)
- 78pF
- RDS(on)
- 85mΩ@10V
- Number
- 1 P-Channel
- Gate Charge(Qg)
- 7.1nC@4.5V
- Gate Threshold Voltage (Vgs(th))
- 3V
- Type
- P-Channel
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.036 g
Overview
Applications
- Reverse Battery protection
- Load switch
- Power management
- Motor Control
Key features
- AEC-Q101 qualified
- Split-gate trench MOSFET technology
- Excellent thermal dissipation package
- Moisture Sensitivity Level 1
- Halogen-free, "green" device
- Epoxy meets UL 94 V-0 flammability rating
- Lead-free finish/RoHS compliant (suffix "P" indicates RoHS compliance, see ordering information)
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | FDC365P#C22435047TECH PUBLIC · SOT-23-6 | TECH PUBLIC | SOT-23-6 | 1,155 | ₹19.22 · 1,155 in stock | View |
 | TPZXMP4A57E6TA#C22435162TECH PUBLIC · SOT-23-6 | TECH PUBLIC | SOT-23-6 | 185 | ₹12.38 · 185 in stock | View |
 | TPM404PS6#C22435153TECH PUBLIC · SOT-23-6 | TECH PUBLIC | SOT-23-6 | 205 | ₹15.48 · 205 in stock | View |
 | TPSQ3419EV-T1-GE3#C22435158TECH PUBLIC · SOT-23-6 | TECH PUBLIC | SOT-23-6 | 2,655 | ₹20.22 · 2,655 in stock | View |
