VISHAYDatasheet (PDF)
IRF9540PBF
P-Channel 100V 19A 150W Through Hole TO-220AB
TO-220ABROHS3 CompliantActive
MOSFET P-CH 100V 19A TO-220AB
- Manufacturer
- VISHAY
- Manufacturer part #
- IRF9540PBF
- Store part #
- C183014
- Package / case
- TO-220AB
- Category
- Single FETs, MOSFETs
- Packaging
- Tube-packed
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,190 in stock
#C183014
Stock & price checked 12 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹204.93 | ₹204.93 |
| 10+ | ₹178.67 | ₹1,786.70 |
| 50+ | ₹153.27 | ₹7,663.50 |
| 100+ | ₹136.98 | ₹13,698.00 |
| 500+ | ₹129.61 | ₹64,805.00 |
| 1,000+ | ₹126.35 | ₹1,26,350.00 |
1 × ₹204.93
₹204.93
excl. GST
₹241.82 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 50 per tube
IRF9540PBF
₹204.93 for 1 + GST
Specifications
- Output Capacitance(Coss)
- 590pF
- Ciss-Input Capacitance
- 1.4nF
- Pd - Power Dissipation
- 150W
- Operating Temperature
- -55℃~+175℃
- Drain to Source Voltage
- 100V
- Current - Continuous Drain(Id)
- 19A
- Reverse Transfer Capacitance (Crss)
- 140pF
- RDS(on)
- 200mΩ@10V
- Number
- 1 P-Channel
- Gate Charge(Qg)
- 61nC@10V
- Vgs
- ±20V
- Gate Threshold Voltage (Vgs(th))
- 4V
- Type
- P-Channel
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tube-packed
- Standard pack
- 50 / Tube
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 2.9 g
Overview
Third generation Power MOSFETs provide the designer with the best combination of fast switching, ruggedized device design, low on-resistance and cost-effectiveness. The TO-220AB package is universally preferred for all commercial-industrial applications at power dissipation levels to approximately 50 W. The low thermal resistance and low package cost of the TO-220AB contribute to its wide acceptance throughout the industry.
Key features
- Dynamic dV/dt Rating
- Repetitive Avalanche Rated
- P-Channel
- 175 °C Operating Temperature
- Fast Switching
- Ease of Paralleling
- Simple Drive Requirements
- Compliant to RoHS Directive 2002/95/EC
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | IRF9540NPBF#C2575Infineon · TO-220 | Infineon | TO-220 | 76,740 | ₹47.54 · 76,740 in stock | View |
 | CMP5210#C17702031Cmos · TO-220 | Cmos | TO-220 | 190 | ₹130.67 · 190 in stock | View |
 | IRF5210PBF-JSM#C18188863JSMSEMI · TO-220-3L | JSMSEMI | TO-220-3L | 140 | ₹124.76 · 140 in stock | View |
 | CMP5940B#C5203734Cmos · TO-220 | Cmos | TO-220 | 103 | ₹58.12 · 103 in stock | View |
| RX3P12BATC16#C20109391ROHM · TO-220AB | ROHM | TO-220AB | 20 | ₹762.46 · 20 in stock | View | |
