IRFS7540TRLPBF
N-Channel 60V 110A 160W Surface Mount D2PAK
D2PAKROHS3 CompliantActive
MOSFET N-CH 60V 110A D2PAK
- Manufacturer
- Infineon
- Manufacturer part #
- IRFS7540TRLPBF
- Store part #
- C538035
- Package / case
- D2PAK
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
15 in stock
#C538035
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹615.50 | ₹615.50 |
| 10+ | ₹530.92 | ₹5,309.20 |
| 30+ | ₹480.62 | ₹14,418.60 |
| 100+ | ₹429.70 | ₹42,970.00 |
| 500+ | ₹406.29 | ₹2,03,145.00 |
| 800+ | ₹395.83 | ₹3,16,664.00 |
1 × ₹615.50
₹615.50
excl. GST
₹726.29 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 800 per reel
IRFS7540TRLPBF
₹615.50 for 1 + GST
Specifications
- Operating Temperature
- -55℃~+175℃
- Drain to Source Voltage
- 60V
- Output Capacitance(Coss)
- 415pF
- Current - Continuous Drain(Id)
- 110A
- Pd - Power Dissipation
- 160W
- RDS(on)
- 4.2mΩ@10V
- Number
- 1 N-channel
- Gate Charge(Qg)
- 130nC@10V
- Vgs
- ±20V
- Type
- N-Channel
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 800 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 2 g
Overview
Applications
- Brushed motor drive applications
- Brushless DC motor drive applications
- Battery-powered circuits
- Half-bridge and full-bridge topologies
- Synchronous rectifier applications
- Resonant mode power supplies
- OR-ing and redundant power switching
- DC/DC and AC/DC converters
- DC/AC inverters
Key features
- Improved gate, avalanche, and dynamic dV/dt robustness
- Fully characterized capacitance and avalanche SOA
- Enhanced body diode dV/dt and dI/dt capability
- Lead-free, RoHS compliant
