VBsemi ElecDatasheet (PDF)
IRLZ34SPBF-VB
N-Channel 60V 50A 150W Surface Mount TO-263(D2PAK)
TO-263(D2PAK)ROHS CompliantActive
MOSFET N-CH 60V 50A TO-263(D2PAK)
- Manufacturer
- VBsemi Elec
- Manufacturer part #
- IRLZ34SPBF-VB
- Store part #
- C7568949
- Package / case
- TO-263(D2PAK)
- Category
- Single FETs, MOSFETs
- Packaging
- Tube-packed
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
13 in stock
#C7568949
Stock & price checked 11 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹99.99 | ₹99.99 |
| 10+ | ₹81.30 | ₹813.00 |
| 50+ | ₹71.84 | ₹3,592.00 |
| 100+ | ₹62.60 | ₹6,260.00 |
| 500+ | ₹57.14 | ₹28,570.00 |
| 1,000+ | ₹54.20 | ₹54,200.00 |
1 × ₹99.99
₹99.99
excl. GST
₹117.99 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 50 per tube
IRLZ34SPBF-VB
₹99.99 for 1 + GST
Specifications
- Operating Temperature
- -55℃~+175℃
- Drain to Source Voltage
- 60V
- Output Capacitance(Coss)
- 1nF
- Current - Continuous Drain(Id)
- 50A
- Ciss-Input Capacitance
- 3nF
- Pd - Power Dissipation
- 150W
- Reverse Transfer Capacitance (Crss)
- 200pF
- RDS(on)
- 23mΩ@10V
- Number
- 1 N-channel
- Gate Charge(Qg)
- 66nC@5V
- Gate Threshold Voltage (Vgs(th))
- 1.9V
- Type
- N-Channel
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tube-packed
- Standard pack
- 50 / Tube
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 3.35 g
Overview
Applications
- Server and telecom power supplies
- Switch mode power supplies (SMPS)
- Power factor correction (PFC)
- Lighting
- High intensity discharge (HID) lamps
- Fluorescent lamp ballast lighting
- Industrial applications
Key features
- Halogen-free According to IEC 61249-2- Definition
- Surface Mount
- Available in Tape and Reel
- Dynamic dV/dt Rating
- Logic-Level Gate Drive
- Fast Switching
- Compliant to RoHS Directive 2002/95/EC
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | IRLZ34NSPBF-VB#C7568762VBsemi Elec · TO-263(D2PAK) | VBsemi Elec | TO-263(D2PAK) | 22 | ₹136.26 · 22 in stock | View |
 | RF1S30N06LESM-VB#C7568817VBsemi Elec · TO-263(D2PAK) | VBsemi Elec | TO-263(D2PAK) | 4 | ₹101.16 · 4 in stock | View |
 | IRFZ44ESPBF-VB#C5179538VBsemi Elec · TO-263(D2PAK) | VBsemi Elec | TO-263(D2PAK) | 4 | ₹97.81 · 4 in stock | View |
 | SIHLZ44S-VB#C22389663VBsemi Elec · TO-263(D2PAK) | VBsemi Elec | TO-263(D2PAK) | 10 | ₹96.00 · 10 in stock | View |
 | VBL1632#C480990VBsemi Elec · TO-263(D2PAK) | VBsemi Elec | TO-263(D2PAK) | 41 | ₹102.20 · 41 in stock | View |
